Perfect for users, even better for IT managers

Power packed and business ready, the ThinkCentre M Series, which includes the Tower, SFF, Tiny, and Thin Client, is the perfect choice for progressive IT managers looking for high-performance, reliable, and secure desktops. Easy to set up, deploy, and manage in any office environment, they boast the latest processing, memory, and storage technology, and have a number of large storage capacity options. In addition, they come with robust security features to safeguard your critical data and the built-in reliability your organization can count on.

For real results, you need real power

With the latest generation of Intel® processors, cutting-edge DDR4 memory, and the option of solid-state storage, the compact ThinkCentre M920 Tiny is as powerful and responsive as a full-sized desktop. It enables you to get more things done, more quickly—and with more elbow room, too.

What are you waiting for?

For an even faster, smoother, and more responsive PC experience, opt for a hard drive with Intel® Optane™ memory. By recognizing the way you work, this smart next-gen technology accelerates everything—from booting up and opening large apps, to finding files fast and multitasking seamlessly.

It's good to have high-speed connections

When it comes to ports, the ThinkCentre M920 Tiny has plenty. It includes USB 3.1 Gen 2 technology for faster charging and data transfers, even if your PC is shut down or in sleep mode. The ports are placed conveniently, too—enabling you to hook up an extra hard drive or monitor in seconds.

Can fit—and work—anywhere

On a bookshelf, behind a monitor, under the desk…you can fit your ThinkCentre M920 Tiny anywhere. What’s more, it’s been rigorously tested to MIL-SPEC standards, so it works in almost any environment—from the Arctic to the desert and everywhere in between.

Easy to use, configure, & upgrade

If your PC is out of reach, you can switch it on remotely with a simple shortcut, Alt+P. The ThinkCentre M920 Tiny also has a number of expansion slots, enabling it to be configured to meet your business needs. What’s more, should you need to swap out any components, you can slide off the side panel without any tools.

Go green, save green

With Energy Star® 7.0 and EPEAT™ Gold ratings, the ThinkCentre M920 Tiny is proven to be extremely energy efficient, resulting in cost savings in the long run. It also runs very quietly and proudly bears the world's first Ultra Low Noise Certificate, awarded by TÜV Rheinland.

One less thing to worry about

Every ThinkCentre M920 Tiny is equipped with Smart USB Protection. It lets you restrict what USB devices can access the PC, while ensuring that no malware enters the system or network through USB ports. In addition, there's TPM, or the Trusted Platform Module, providing hardware-based security, including the generating and storing of cryptographic keys, while a Kensington Lock port lets you physically secure your M920 Tiny.

Specification

Product
Product id	688627
Brand	Lenovo
Partnr	10T1S0170M
EAN/UPC code	195042586756
Processor
Processor manufacturer	Intel
Processor family	Intel Core i5
Processor generation	Intel Core i5-9xxx
Processor model	i5-9600T
Processor cores	6
Processor frequency	2.3 GHz
Processor boost frequency	3.9 GHz
Processor socket	LGA 1151 (Socket H4)
Processor cache	9 MB
Processor cache type	Smart Cache
Processor threads	6
System bus rate	8 GT/s
Processor lithography	14 nm
Processor operating modes	64-bit
Thermal Design Power (TDP)	35 W
Processor codename	Coffee Lake
Configurable TDP-down	25 W
Configurable TDP-down frequency	1.8 GHz
Tjunction	100 °C
Maximum number of PCI Express lanes	16
PCI Express slots version	3.0
PCI Express configurations	1x16, 2x8, 1x8+2x4
Number of processors installed	1
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Memory bandwidth supported by processor (max)	41.6 GB/s
Memory
Internal memory	8 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory slots	2x SO-DIMM
Memory clock speed	2666 MHz
Non-ECC	Y
Storage
Total storage capacity	128 GB
Optical drive type	N
Card reader integrated	N
Storage media	SSD
Number of storage drives installed	1
Total SSDs capacity	128 GB
Number of SSDs installed	1
SSD capacity	128 GB
Graphics
Discrete graphics adapter	N
On-board graphics adapter	Y
Discrete graphics adapter model	Not available
On-board GPU manufacturer	Intel
On-board graphics adapter model	Intel UHD Graphics 630
Maximum on-board graphics adapter memory	64 GB
Number of displays supported (on-board graphics)	3
On-board graphics adapter dynamic frequency (max)	1150 MHz
On-board graphics adapter base frequency	350 MHz
On-board graphics adapter ID	0x3E92
On-board graphics adapter DirectX version	12.0
On-board graphics adapter OpenGL version	4.5
Network
Ethernet LAN	Y
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
DVI port	N
HDMI ports quantity	1
DisplayPorts quantity	1
Ethernet LAN (RJ-45) ports	1
Microphone in	Y
Headphone outputs	1
Combo headphone/mic port	Y
Design
Chassis type	Mini PC
Volume	1 l
VESA mounting	Y
Placement supported	Horizontal/Vertical
Product colour	Black
Performance
Product type	Mini PC (<= 3L)
Motherboard chipset	Intel Q370
Password protection	Y
Software
Operating system installed	Windows 10 Pro
Operating system architecture	64-bit
Processor special features
Thermal solution specification	PCG 2015A
CPU configuration (max)	1
Scalability	1S
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Processor package size	37.5 x 37.5 mm
Intel Software Guard Extensions (Intel SGX)	Y
Intel Virtualization Technology for Directed I/O (VT-d)	Y
Processor ARK ID	191051
Intel Virtualization Technology (VT-x)	Y
Enhanced Intel SpeedStep Technology	Y
Intel 64	Y
Intel® InTru™ 3D Technology	Y
Intel® Clear Video HD Technology (Intel® CVT HD)	Y
Execute Disable Bit	Y
Intel Trusted Execution Technology	Y
Intel® OS Guard	Y
Intel® Secure Key	Y
Intel® AES New Instructions (Intel® AES-NI)	Y
Intel Stable Image Platform Program (SIPP)	Y
Thermal Monitoring Technologies	Y
Embedded options available	N
Intel Clear Video Technology	Y
Intel VT-x with Extended Page Tables (EPT)	Y
Intel TSX-NI	Y
Idle States	Y
Intel® Turbo Boost Technology	2.0
Intel® Hyper Threading Technology (Intel® HT Technology)	N
Intel® Quick Sync Video Technology	Y
Intel® Identity Protection Technology (Intel® IPT)	Y
Certificates
Certification	MIL-STD-810G
Weight & dimensions
Width	179 mm
Depth	182.9 mm
Height	34.5 mm
Weight	1320 g
Packaging content
Display included	N
