Tiny technology, big output
The 1L ThinkCentre M75q Gen 2 tiny desktop PC is built to do big things. It will fit anywhere in your workspace, where its powerful AMD PRO performance will keep your business going. It’s also easy to manage and expand, with a durable design and convenient features.

Full-sized performance
At 1L, the ThinkCentre M75q Gen 2 can be tucked away anywhere, while providing enterprise-level performance with its AMD Ryzen™ 7 PRO processor. This PC is designed for multitasking, content creation, data-crunching, and more—all from a compact unit. It also features up to two DDR4 SODIMM slots and dual punch-outs, allowing you to configure it to meet your specific business needs.

Secure inside and out
Work fearlessly, thanks to the reinforced security of ThinkShield—the most comprehensive, end-to-end security solution on the market. ThinkShield combines industry-leading hardware, software, services, and processes to protect your data and your business. This PC also features AMD Memory Guard, providing full memory encryption to protect sensitive data.

Enhanced experience, easy expandability
The M75q Gen 2 is designed to grow with your business. It connects to industry-specific equipment as well as legacy peripherals, and is built for easy expansion. It’s also designed with people—and shrinking workspaces—in mind. It fits easily into any environment, connects to up to three displays, and allows fast charging and data sharing via its front-panel USB-C port.

Comprehensive manageability and reliability
The M75q Gen 2 is easy to deploy, upgrade, and manage. It features built-in driver support for older OS versions and toolless access. AMD PRO manageability allows IT professionals to administer to a full fleet from any location within your organization. It's easy to connect to a Tiny-in-One display, among other mounting options. And it’s MILSPEC-tested against 10 conditions for durability and reliability.

Specification

Product
Product id	862405
Brand	Lenovo
Partnr	11JN000JMH
EAN/UPC code	196118833644
Processor
Processor manufacturer	AMD
Processor family	AMD Ryzen 7 PRO
Processor model	5750GE
Processor cores	8
Processor frequency	3.2 GHz
Processor boost frequency	4.6 GHz
Processor cache type	L3
Processor threads	16
Memory
Internal memory	16 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	1 x 16 GB
Memory slots	2x SO-DIMM
Memory clock speed	3200 MHz
Memory channels	Dual-channel
Storage
Total storage capacity	512 GB
Optical drive type	N
Storage media	SSD
Number of storage drives installed	1
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
SSD interface	PCI Express
NVMe	Y
SSD form factor	M.2
Graphics
Discrete graphics adapter	N
On-board graphics adapter	Y
Discrete graphics adapter model	Not available
On-board graphics adapter model	AMD Radeon Graphics
Network
Ethernet LAN	Y
Ethernet LAN data rates	100, 1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	Wi-Fi 5 (802.11ac)
WLAN controller model	Realtec RTL8822CE
Antenna type	2x2
Bluetooth	Y
Bluetooth version	5.0
Wake-on-LAN ready	Y
Ports & interfaces
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
HDMI ports quantity	1
DisplayPorts quantity	2
Ethernet LAN (RJ-45) ports	1
Combo headphone/mic port	Y
Design
Chassis type	Mini PC
Volume	1 l
Placement supported	Horizontal/Vertical
Water cooling system	N
Cable lock slot	Y
Cable lock slot type	Kensington
Product colour	Black
Viewing window	N
Performance
Product type	Mini PC (<= 3L)
Motherboard chipset	AMD PRO 500
Audio chip	Realtek ALC222
Audio system	High Definition Audio
Built-in speaker(s)	Y
Number of speakers	1
Password protection	Y
Password protection type	Power on, Supervisor, HDD
Trusted Platform Module (TPM)	Y
Software
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Operating system language	DEU, DUT, ENG, FRE, ITA
Recovery operating system	Windows 10 Pro
Power
Power supply	65 W
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	20 - 80 procent
Storage relative humidity (H-H)	10 - 90 procent
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 12192 m
Certificates
Certification	ErP Lot 3
Weight & dimensions
Width	179 mm
Depth	183 mm
Height	37 mm
Weight	1250 g
Packaging content
Display included	N
Mouse included	Y
Keyboard included	Y
Technical details
Sustainability certificates	ENERGY STAR, RoHS, TCO
