Product |
Product id
| 800139
|
Brand
| Lenovo
|
Partnr
| 20TD00JXMH
|
EAN/UPC code
| 196119649749
|
Design |
Product type
| Notebook
|
Product colour
| Black
|
Form factor
| Clamshell
|
Housing material
| Acrylonitrile butadiene styrene (ABS), Aluminium, Polycarbonate (PC)
|
Display |
Display diagonal
| 15.6 inch
|
Display resolution
| 1920 x 1080 Pixels
|
Touchscreen
| N
|
Panel type
| IPS
|
HD type
| Full HD
|
LED backlight
| Y
|
Native aspect ratio
| 16:9
|
Anti-glare screen
| Y
|
Display brightness
| 250 cd/m²
|
Colour gamut
| 45 procent
|
RGB colour space
| NTSC
|
Contrast ratio (typical)
| 800:1
|
Processor |
Processor manufacturer
| Intel
|
Processor family
| Intel Core i5
|
Processor model
| i5-1135G7
|
Processor generation
| Intel Core i5-11xxx
|
Processor boost frequency
| 4.2 GHz
|
Processor cores
| 4
|
Processor cache
| 8 MB
|
Configurable TDP-up frequency
| 2.4 GHz
|
Configurable TDP-up
| 28 W
|
Configurable TDP-down
| 12 W
|
Configurable TDP-down frequency
| 0.9 GHz
|
Memory |
Internal memory
| 8 GB
|
Internal memory type
| DDR4-SDRAM
|
Memory clock speed
| 3200 MHz
|
Memory form factor
| SO-DIMM
|
Memory layout (slots x size)
| 1 x 8 GB
|
Memory slots
| 1x SO-DIMM
|
Maximum internal memory
| 32 GB
|
Storage |
Total storage capacity
| 256 GB
|
Storage media
| SSD
|
Total SSDs capacity
| 256 GB
|
Number of SSDs installed
| 1
|
SSD capacity
| 256 GB
|
SSD interface
| NVMe, PCI Express 3.0
|
NVMe
| Y
|
SSD form factor
| M.2
|
Optical drive type
| N
|
Card reader integrated
| N
|
Graphics |
On-board graphics adapter
| Y
|
Discrete graphics adapter
| N
|
Discrete graphics adapter model
| Not available
|
On-board graphics adapter model
| Intel Iris Xe Graphics
|
Audio |
Audio chip
| Realtek ALC3287
|
Audio system
| Dolby Audio
|
Number of built-in speakers
| 2
|
Speakers manufacturer
| Harman Kardon
|
Speaker power
| 2 W
|
Built-in subwoofer
| N
|
Built-in microphone
| Y
|
Number of microphones
| 2
|
Camera |
Front camera
| Y
|
Front camera HD type
| HD
|
Infrared (IR) camera
| Y
|
Privacy camera
| Y
|
Privacy type
| Privacy shutter
|
Network |
Bluetooth
| Y
|
Mobile network connection
| N
|
Top Wi-Fi standard
| Wi-Fi 6 (802.11ax)
|
Wi-Fi standards
| Wi-Fi 6 (802.11ax)
|
Antenna type
| 2x2
|
WLAN controller manufacturer
| Intel
|
WLAN controller model
| Intel Wi-Fi 6 AX201
|
Ethernet LAN
| Y
|
Ethernet LAN data rates
| 100,1000 Mbit/s
|
Bluetooth version
| 5.2
|
Near Field Communication (NFC)
| N
|
WWAN
| N
|
Ports & interfaces |
USB 2.0 ports quantity
| 1
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
| 1
|
Ethernet LAN (RJ-45) ports
| 1
|
HDMI ports quantity
| 1
|
HDMI version
| 1.4b
|
Intel® Thunderbolt 4
| Y
|
Combo headphone/mic port
| Y
|
Thunderbolt 4 ports quantity
| 1
|
USB Type-C DisplayPort Alternate Mode
| Y
|
USB Power Delivery
| Y
|
USB Sleep-and-Charge
| Y
|
USB Sleep-and-Charge ports
| 1
|
Keyboard |
Pointing device
| ThinkPad UltraNav
|
Keyboard layout
| QWERTY
|
Keyboard language
| English
|
Keyboard backlit
| Y
|
Numeric keypad
| Y
|
Spill-resistant keyboard
| Y
|
Software |
Operating system installed
| Windows 11 Pro
|
Operating system architecture
| 64-bit
|
Operating system language
| DEU, DUT, ENG, FRE, ITA
|
Processor special features |
Idle States
| Y
|
Intel Virtualization Technology for Directed I/O (VT-d)
| Y
|
CPU configuration (max)
| 1
|
Embedded options available
| N
|
Intel Virtualization Technology (VT-x)
| Y
|
Intel Software Guard Extensions (Intel SGX)
| N
|
Intel Stable Image Platform Program (SIPP)
| N
|
Intel VT-x with Extended Page Tables (EPT)
| Y
|
Intel Trusted Execution Technology
| N
|
Battery |
Battery technology
| Lithium Polymer (LiPo)
|
Battery capacity (Watt-hours)
| 45 Wh
|
Battery life (max)
| 10.8 uur
|
Quick charge
| Y
|
Power |
AC adapter power
| 65 W
|
Security |
Cable lock slot
| Y
|
Cable lock slot type
| Kensington
|
Fingerprint reader
| Y
|
Trusted Platform Module (TPM)
| Y
|
Trusted Platform Module (TPM) version
| 2.0
|
Password protection
| Y
|
Password protection type
| HDD, Power on, Supervisor
|
Operational conditions |
Operating temperature (T-T)
| 5 - 35 °C
|
Storage temperature (T-T)
| 5 - 43 °C
|
Operating relative humidity (H-H)
| 8 - 95 procent
|
Storage relative humidity (H-H)
| 5 - 95 procent
|
Certificates |
Certification
| ErP lot3, TUV Low Blue Light, MIL-STD-810H
|
Weight & dimensions |
Weight
| 1700 g
|
Width
| 365 mm
|
Depth
| 240 mm
|
Height
| 18.9 mm
|
Logistics data |
Harmonized System (HS) code
| 84713000
|
Technical details |
Sustainability certificates
| ENERGY STAR, EPEAT Gold, RoHS, TCO
|
