RELIABLE PERFORMANCE
Redefining Power & Portability

The 16" Lenovo ThinkPad T1g Gen 8 laptop is built for professionals who demand high performance in a sleek, portable design. Powered by Intel® Core™ Ultra (Series 2) processors and NVIDIA® GeForce RTX® graphics, it delivers powerful computing, making it ideal for power users, digital creators, and gamers.

AI-DRIVEN EFFICIENCY
Simplify Work, Accelerate Results

Revolutionize your workflow and elevate productivity with advanced AI processing power. Simplify tasks, automate processes, and work smarter with AI-driven tools that integrate effortlessly into professional applications. Achieve faster iterations and more efficient content creation — ideal for professionals who demand quick and effective results.

STUNNING DISPLAY
Visual Brilliance & Perfection in Every Pixel

The 16ʺ ThinkPad T1g Gen 8 redefines visual experience with advanced display options, featuring Tandem OLED (T-OLED) technology. Immerse yourself in breathtaking colour accuracy, rich contrast, and brilliant brightness. Built for digital creators and gamers, it delivers outstanding outdoor clarity and efficient power use for unstoppable on-the-go performance.

CREDIBILITY & COLLABORATION
Sustainability.

Our goal is to provide smarter technology that builds a brighter, more sustainable future for our customers, communities, and the planet. That's why we pursue industry leading labels and certifications that demonstrate our commitment to sustainability in product design. Together, we can build a smarter future for all.

Specifications may vary depending upon region / model.

Specification

Product
Product id	1003776
Brand	Lenovo
Partnr	21TD0005MH
EAN/UPC code	199272088967
Warranty (months)	3-year, Courier or Carry-in with 1-year Battery + 3Y Premier TP WS WHB (CPN), CO2 Offset 0.5 ton (2nd Generation Carbon Offset Projects)
Design
Product type	Notebook
Product colour	Black
Form factor	Clamshell
Housing material	Aluminium
Display
Display diagonal	16 inch
Display resolution	3840 x 2400 Pixels
Touchscreen	Y
Panel type	IPS
HD type	WQUXGA
LED backlight	Y
Native aspect ratio	16:10
Anti-glare screen	Y
Display brightness	800 cd/m²
Colour gamut	100 procent
RGB colour space	DCI-P3
High Dynamic Range (HDR) technology	DisplayHDR 400, Dolby Vision
Maximum refresh rate	60 Hz
Contrast ratio (typical)	1500:1
High Dynamic Range (HDR) supported	Y
Processor
Processor manufacturer	Intel
Processor family	Intel Core Ultra 9
Processor model	285H
Processor generation	Intel Core Ultra (Series 2)
Processor boost frequency	5.4 GHz
Processor cores	16
Processor threads	16
Low Power Efficient-cores	2
Efficient-core base frequency	2.7 GHz
Efficient-core Max Turbo Frequency	4.5 GHz
Low Power Efficient-core Max Turbo Frequency	2.5 GHz
Processor cache	24 MB
Performance-core base frequency	2.9 GHz
Performance-core Max Turbo Frequency	5.4 GHz
Low Power Efficient-core Base Frequency	1000 MHz
Motherboard chipset	Intel SoC
Processor base power	45 W
Maximum turbo power	115 W
Performance cores	6
Efficient cores	8
Memory
Internal memory	64 GB
Internal memory type	LPDDR5x-SDRAM
Memory clock speed	7467 MHz
Memory form factor	LPCAMM2
Maximum internal memory	64 GB
Memory channels	Dual-channel
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Y
Windows Studio effects support	Y
AI software frameworks supported by NPU	DirectML, OpenVINO, Windows ML, ONNX RT, WebNN
Total processor performance (up to)	99 TOPs
NPU performance up to	13 TOPs
GPU performance up to	77 TOPs
Storage
Total storage capacity	2000 GB
Storage media	SSD
Total SSDs capacity	2000 GB
Number of SSDs installed	1
SSD capacity	2000 GB
SSD interface	PCI Express 5.0
NVMe	Y
SSD form factor	M.2
M.2 SSD size	2280 (22 x 80 mm)
Optical drive type	N
Card reader integrated	Y
Compatible memory cards	SD
Graphics
On-board graphics adapter	Y
Discrete graphics adapter	Y
Discrete GPU manufacturer	NVIDIA
Discrete graphics adapter model	NVIDIA GeForce RTX 5070
On-board graphics adapter family	Intel Arc Graphics
On-board GPU manufacturer	Intel
On-board graphics adapter model	Intel Arc 140T
Discrete graphics adapter memory	8 GB
Discrete graphics memory type	GDDR7
Audio
Audio chip	Cirrus Logic CS42L43
Audio system	Dolby Atmos
Number of built-in speakers	2
Speaker power	2 W
Built-in microphone	Y
Number of microphones	2
Camera
Front camera	Y
Front camera resolution (numeric)	5 MP
Infrared (IR) camera	Y
Privacy camera	Y
Privacy type	Privacy shutter
Network
Bluetooth	Y
Mobile network connection	N
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	Wi-Fi 7 (802.11be)
Antenna type	2x2
WLAN controller manufacturer	Intel
Ethernet LAN	N
Bluetooth version	5.4
Near Field Communication (NFC)	N
WWAN	Not installed
Ports & interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
HDMI ports quantity	1
HDMI version	2.1
Intel® Thunderbolt 4	Y
Combo headphone/mic port	Y
Thunderbolt 4 ports quantity	1
Thunderbolt 5 ports quantity	2
Intel® Thunderbolt 5	Y
USB Type-C DisplayPort Alternate Mode	Y
USB Power Delivery	Y
USB Sleep-and-Charge	Y
USB Sleep-and-Charge ports	1
Keyboard
Pointing device	ThinkPad UltraNav
Keyboard language	English
Keyboard backlit	Y
Numeric keypad	N
Spill-resistant keyboard	Y
Copilot key	Y
Software
Operating system installed	Windows 11 Pro
Operating system architecture	64-bit
Operating system language	DEU, DUT, ENG, FRE, ITA
Bundled software	Intel Connectivity Performance Suite + Lenovo AI Now
Battery
Battery technology	Lithium-Ion (Li-Ion)
Battery capacity (Watt-hours)	90 Wh
Quick charge	Y
Power
AC adapter power	140 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
USB Type-C charging port	Y
Security
Cable lock slot	Y
Cable lock slot type	Kensington
Fingerprint reader	Y
Smart card reader	N
Windows Hello	Y
Trusted Platform Module (TPM)	Y
Trusted Platform Module (TPM) version	2.0
Password protection	Y
Password protection type	Power on, SSD, Supervisor
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	5 - 43 °C
Operating relative humidity (H-H)	8 - 95 procent
Storage relative humidity (H-H)	5 - 95 procent
Maximum shipping altitude	3048 m
Certificates
Certification	ENERGY STAR 9.0 EPEAT Gold Registered RoHS compliant TCO Certified, generation 10
Weight & dimensions
Weight	1840 g
Width	354.3 mm
Depth	241 mm
Height (front)	9.9 mm
Height (rear)	15.8 mm
Other features
AC adapter included	Y
