High-level performance without the high price
From large workloads to multitasking, the compact ThinkStation P520c breezes through it all. With cutting-edge processing, graphics, storage, and memory, this configurable 25L workstation is a solid workhorse. Energy efficient and extremely reliable, it's also ISV-certified and VR-ready. Equally impressive is the affordable price tag.

Real power at a reasonable price

For true processing power and blazing-fast visuals, power up the ThinkStation P520c. Fueled by the latest Intel® Xeon® processors and NVIDIA® Quadro® graphics, this compact 25L workhorse can help you to get the job done, quickly and easily. What's more, it comes at a very affordable price.

Configurable and reliable

The P520c can be configured to meet your specific needs, including up to 128 GB of memory and solid-state or hard disk drive storage options. One thing you won't have to worry about, however, is reliability, which is the cornerstone of every ThinkStation.

Enhanced flexible design

With two M.2 PCIe solid state drive slots embedded in the motherboard, you can enjoy blistering-fast storage speeds. What's more, the front FLEX module gives you a range of options and flexibility, including a media card reader and blazing-fast Intel® Thunderbolt™ 3 port.

Hassle-free, tool-free

Should you ever need to swap any components, there’s no need to worry about tools. Simply slide off the side panel and away you go. You may also wish to know that we can help automate many of the manual tasks associated with deploying new machines, from asset tagging to custom image loading.

Ready for anything, real or virtual

With virtual reality (VR), almost anything's possible—from revolutionary designs to stunning special effects to highly complex simulations. With the powerful P520c and top-of-the range, high-performance NVIDIA Quadro® graphics (optional), a truly immersive VR experience awaits.

Built-in peace of mind

Like every ThinkStation before it, the P520c has undergone rigorous testing under extreme conditions. It's also ISV-certified and boasts error-correcting code (ECC) memory, ensuring even greater accuracy and reliability.

A helping hand when you need it

You’ll be able to keep your P520c running at its peak thanks to Lenovo Workstation Diagnostics. Available for both desktop and smartphone, this intelligent app can help you diagnose and troubleshoot potential system issues by providing step-by-step guidance on optimal system performance. And should your machine ever fail to boot, an error code for additional assistance will be sent wirelessly to your smartphone.

In addition, there's Lenovo Performance Tuner. Free to download and easy to use, this software can help you fine-tune your workstation to get even more out of it.

Better for the planet—and your bottom line

The P520c meets some of the world's most comprehensive environmental standards. A GREENGUARD®-certified workstation, it has also been rated EPEAT Gold, ENERGY STAR 6.1, and up to 80 PLUS® Platinum PSU. And as a result of its energy efficiency, the P520c can even help lower your utility bills.

Specification

Product
Product id	862410
Brand	Lenovo
Partnr	30BX00GQMH
EAN/UPC code	196379908631
Processor
Processor manufacturer	Intel
Processor family	Intel Xeon W
Processor model	W-2245
Processor cores	8
Processor frequency	3.9 GHz
Processor boost frequency	4.5 GHz
Processor cache	16.5 MB
Number of processors installed	1
Memory
Internal memory	32 GB
Internal memory type	DDR4-SDRAM
Memory slots	4x DIMM
Memory clock speed	2933 MHz
ECC	Y
Storage
Total storage capacity	1000 GB
Optical drive type	N
Card reader integrated	Y
Storage media	SSD
Number of storage drives installed	1
Total SSDs capacity	1000 GB
Number of SSDs installed	1
SSD capacity	1000 GB
SSD interface	PCI Express
NVMe	Y
SSD form factor	M.2
Graphics
Discrete graphics adapter	Y
Discrete GPU manufacturer	NVIDIA
Discrete graphics adapter model	NVIDIA Quadro T1000
Discrete graphics memory type	GDDR6
Discrete graphics adapter memory	8 GB
Number of discrete graphics adapters	1
Graphics card Mini DisplayPort ports quantity	4
Network
Ethernet LAN	Y
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Wi-Fi	N
Bluetooth	N
Ports & interfaces
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
DVI port	N
PS/2 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Microphone in	Y
Headphone outputs	1
Line-in	Y
Line-out	Y
Design
Chassis type	Tower
Volume	25 l
Product colour	Black
Performance
Product type	Workstation
Motherboard chipset	Intel C422
Audio chip	Realtek ALC662
Audio system	High Definition Audio
Password protection	Y
Password protection type	Power on
Trusted Platform Module (TPM)	Y
Software
Operating system installed	Windows 11 Pro for Workstations
Operating system architecture	64-bit
Operating system language	DEU, DUT, ENG, FRE, ITA
Processor special features
CPU configuration (max)	1
Intel Software Guard Extensions (Intel SGX)	N
Intel Demand Based Switching	Y
Intel Virtualization Technology for Directed I/O (VT-d)	Y
Intel Virtualization Technology (VT-x)	Y
Intel Flex Memory Access	N
Enhanced Intel SpeedStep Technology	Y
Intel 64	Y
Execute Disable Bit	Y
Intel Trusted Execution Technology	Y
Embedded options available	N
Intel VT-x with Extended Page Tables (EPT)	Y
Intel TSX-NI	Y
Idle States	Y
Power
Power supply	625 W
Power supply input voltage	100 - 240
Power supply input frequency	50/60 Hz
Operational conditions
Operating temperature (T-T)	10 - 35 °C
Storage temperature (T-T)	-10 - 60 °C
Operating relative humidity (H-H)	10 - 80 procent
Operating altitude	-15.2 - 3048 m
Weight & dimensions
Width	175 mm
Depth	426 mm
Height	376 mm
Weight	14500 g
Packaging content
Mouse included	Y
Keyboard included	Y
