The ThinkSystem PM1743 Read Intensive NVMe PCIe 5.0 SSDs, available in capacities up to 15.36TB, are general-purpose yet high-performance NVMe PCIe Gen 5 SSDs. Available in both 2.5-inch and E3. S EDSFF form factors, they are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads. Now with SED encryption as standard, these drives help ensure data security, even when the drive is removed from the server.

This product guide provides essential presales information to understand the PM1743 SSDs and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SSDs and consider their use in IT solutions.

Specification

Product
Product id	1005465
Brand	Lenovo
Partnr	4XB7A82368
EAN/UPC code	889488633135
Certificates
Certification	cUL CE TUV-GS CB CE (EU) BSMI (Taiwan) KC (South Korea) VCCI (Japan) RCM (Australia) FCC (USA) / IC (Canada)
Features
SSD form factor	2.5"
SSD capacity	7680 GB
Interface	PCI Express 5.0
Memory type	V-NAND
NVMe	Y
Component for	Server
Hardware encryption	Y
Random read (4KB)	2500000 IOPS
Random write (4KB)	300000 IOPS
Read latency	60 µs
Write latency	20 µs
S. M. A. R. T. support	Y
ECC	Y
Hot-swap	Y
Uncorrectable Bit Error Rate (UBER)	< 1 per 10^17 bits read
Mean time between failures (MTBF)	2500000 uur
Drive writes per day (DWPD)	1
Operational conditions
Operating relative humidity (H-H)	5 - 95 procent
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
Non-operating vibration	20 G
Non-operating shock	1500 G
Maximum operating altitude	3050 m
Weight & dimensions
Width	70 mm
Depth	100 mm
Height	15 mm
Weight	190 g
