The ThinkSystem 7500 PRO Read Intensive NVMe SSDs are general-purpose yet high-performance family of NVMe solid-state drives. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads. Now with SED encryption as standard, these drives help ensure data security, even when the drive is removed from the server.

This product guide provides essential presales information to understand the ThinkSystem 7500 PRO Read Intensive NVMe SSDs offerings and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the 7500 PRO SSDs and consider their use in IT solutions.

Specification

Product
Product id	1008995
Brand	Lenovo
Partnr	4XB7A95051
EAN/UPC code	889488739677
Certificates
Certification	CE (Europe): EN55032, EN55024 Class B, RoHS FCC: CFR Title 47, Part 15, Class B UL/cUL: approval to UL-60950-1, 2nd Edition, IEC 60950-1:2005 (2nd Edition); EN 60950-1 (2006) + A11:2009+ A1:2010 + A12:2011 + A2:2013 BSMI (Taiwan): approval to CNS 13438, Class B, CNS 15663 RCM (Australia, New Zealand): AS/NZS CISPR32 Class B KC RRL (Korea): approval to KN32 Class B, KN 35 Class B W. E. E. E. : Compliance with EU WEEE directive 2012/19/EC. TUV (Germany): approval to IEC60950/EN60950 VCCI (Japan): 2015-04 Class B IC (Canada): ICES-003 Class B Morocco: EN55032, EN55024 Class B UkrSEPRO (Ukraine): EN55032 Class B, IEC60950/EN60950, RoHS (Resolution 2017 No. 139) UKCA (UK): SI 2016/1091 Class B and SI 2012/3032 RoHS
Features
SSD form factor	U.3
SSD capacity	3840 GB
Interface	PCI Express 4.0
Memory type	3D TLC NAND
NVMe	Y
Component for	Server/Workstation
Hardware encryption	Y
Security algorithms	TCG Opal 2.0
Random read (4KB)	1100000 IOPS
Random write (4KB)	180000 IOPS
Read latency	70 µs
Write latency	15 µs
Uncorrectable Bit Error Rate (UBER)	< 1 per 10^17 bits read
Mean time between failures (MTBF)	2000000 uur
Drive writes per day (DWPD)	1
Power
Power consumption (read)	12.8 W
Power consumption (write)	15.5 W
Operational conditions
Operating relative humidity (H-H)	5 - 95 procent
Operating temperature (T-T)	0 - 70 °C
Non-operating shock	1500 G
Vibration resistance	9.1 G
Weight & dimensions
Width	70 mm
Depth	100 mm
Height	15 mm
Weight	200 g
