Equipped with an Intel Core i5-12450H processor, this SDM-L PC transforms your iiyama large format display into a powerful, standalone solution. It features Intel UHD Graphics, a high-speed M.2 NVMe PCIe SSD, four USB 3.2 Gen1 ports, and two Type-C ports (supporting USB 3.2 Gen1 and DP Alt Mode) for ultimate connectivity.

Specification

Product
Product id	1025499
Brand	iiyama
Partnr	SDM51201BC-1L
EAN/UPC code	4948570033577
Warranty (months)	36 months
Processor
Processor manufacturer	Intel
Processor family	Intel Core i5
Processor model	i5-12450H
Memory
Internal memory	8 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Memory clock speed	3200 MHz
Storage
Total storage capacity	256 GB
Optical drive type	N
Storage media	SSD
Number of storage drives installed	1
SSD capacity	256 GB
SSD interface	PCI Express
NVMe	Y
SSD form factor	M.2
Graphics
Discrete graphics adapter	N
On-board graphics adapter	Y
Discrete GPU manufacturer	Intel
Discrete graphics adapter model	Not available
On-board graphics adapter model	Intel UHD Graphics
Network
Ethernet LAN	Y
Ethernet LAN data rates	10, 100, 1000 Mbit/s
LAN controller	Realtek RTL8111H
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller manufacturer	Intel
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Bluetooth	Y
Bluetooth version	5.3
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	2
USB Type-C DisplayPort Alternate Mode	Y
HDMI ports quantity	1
HDMI version	2.0
DisplayPort version	1.4
Ethernet LAN (RJ-45) ports	1
Microphone in	Y
Combo headphone/mic port	Y
Design
Chassis type	Slot-in PC
Product colour	Black
Performance
Product type	Mini PC (<= 3L)
Audio chip	Realtek ALC245
Audio system	High Definition Audio
Trusted Platform Module (TPM)	Y
Trusted Platform Module (TPM) version	2.0
Software
Operating system installed	Windows 11 IoT Enterprise
Operating system architecture	64-bit
Copilot+ PC	N
Compatible operating systems	Windows 11 loT Enterprise (SAC) 64Bit
Power
Power consumption (typical)	72 W
Power consumption (standby)	0.5 W
Operational conditions
Operating temperature (T-T)	-5 - 45 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	5 - 95 procent
Storage relative humidity (H-H)	5 - 95 procent
Certificates
Compliance certificates	REACH, RoHS, WEEE
Weight & dimensions
Width	110 mm
Depth	195 mm
Height	25 mm
Weight	400 g
Package width	279 mm
Package depth	67 mm
Package height	201 mm
Package weight	610 g
Packaging content
Display included	N
Technical details
Sustainability certificates	ErP
