Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.

Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Intel® ME Firmware Version
Intel® Management Engine Firmware (Intel® ME FW) uses built-in platform capabilities and management and security applications to remotely manage networked computing assets out-of-band.

Max Turbo Frequency
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.

Intel® HD Audio Technology
Intel® High Definition Audio (Intel® HD Audio) is capable of playing back more channels at higher quality than previous integrated audio formats. In addition, Intel® HD Audio has the technology needed to support the latest and greatest audio content.

Integrated Graphics
Integrated graphics allow for incredible visual quality, faster graphic performance and flexible display options without the need for a separate graphics card.

Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.

Intel® Platform Trust Technology (Intel® PTT)
Intel® Platform Trust Technology (Intel® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows® 10. Intel® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.

Specification

Product
Product id	889095
Brand	Intel
Partnr	BNUC12WSBI70000
EAN/UPC code	5032037247528
Warranty (months)	36 months
Processor
Processor manufacturer	Intel
Processor socket	NA (integrated CPU)
Compatible processor series	Intel Core i7
Processor model	i7-1260P
Processor cores	12
Maximum internal memory supported by processor	64 GB
Memory
Supported memory types	DDR4-SDRAM
Number of memory slots	2
Memory slots type	SO-DIMM
Memory channels	Dual-channel
Memory voltage	1.2 V
ECC	N
Non-ECC	Y
Maximum internal memory	64 GB
Supported memory clock speed (max)	3200 MHz
Storage controllers
Supported storage drive types	SSD
Supported storage drive interfaces	M.2
Number of storage drives supported	2
SSD form factor	M.2
Graphics
Parallel processing technology support	Not supported
On-board graphics adapter	N
Graphics adapter family	Intel
Maximum resolution	7680 x 4320 Pixels
OpenGL version	4.6
DirectX version	12.1
Discrete graphics support	N
Number of displays supported	4
On-board graphics adapter model	Intel UHD Graphics
Internal I/O
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
Number of SATA III connectors	1
Number of SATA connectors	1
Total number of SATA connectors	1
Rear panel I/O ports
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	2
HDMI version	2.0b
DisplayPorts quantity	1
Thunderbolt ports quantity	2
USB connector type	USB Type-A
Network
Ethernet LAN	Y
Ethernet interface type	2.5 Gigabit Ethernet
LAN controller	Intel I225-V
Wi-Fi	N
Features
Component for	Mini PC
Motherboard form factor	UCFF
Motherboard chipset family	Intel
Motherboard chipset	Intel SoC
Power source type	DC
Cooling type	Active
DC input voltage	12 - 20 V
Linux operating systems supported	Y
Windows operating systems supported	Windows 10, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 11
Compatible operating systems	Windows 10 IoT Enterprise*|Linux*
Harmonized System (HS) code	8471500150
Expansion slots
PCI Express slots version	4.0
Number of M.2 (M) slots	1
Processor special features
Intel ME Firmware Version	16
Intel Virtualization Technology (VT-x)	Y
Intel Virtualization Technology for Directed I/O (VT-d)	Y
Intel® Platform Trust Technology (Intel® PTT)	Y
Intel® High Definition Audio (Intel® HD Audio)	Y
Intel® AES New Instructions (Intel® AES-NI)	Y
Intel® Optane™ Memory Ready	N
Technical details
M.2 card slot (storage)	2280 NVMe (M); 2242 SATA (B)
M.2 card slot (wireless)	2230 (E-key) (E)
USB ports quantity	4
Expected discontinuance date	1H'25
Launch date	Q3'22
Status	Launched
Other features
Combo headphone/mic port	Y
Additional headers	Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby); Internal 2x2 power connector
Embedded options available	N
Serial port via internal header	N
Number of DIMM slots	2
DC-in jack	Y
Thermal Design Power (TDP)	35 W
Commodity Classification Automated Tracking System (CCATS)	G157815L2
Export Control Classification Number (ECCN)	5A992C
Number of M.2 (E) slots	1
