Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Intel® HD Audio Technology
Intel® High Definition Audio (Intel® HD Audio) is capable of playing back more channels at higher quality than previous integrated audio formats. In addition, Intel® HD Audio has the technology needed to support the latest and greatest audio content.

Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Specification

Product
Product id	721900
Brand	Intel
Partnr	BOXNUC7PJYHN2
EAN/UPC code	5032037220781
Warranty (months)	3 years
Processor
Built-in processor	Y
Processor manufacturer	Intel
Processor family	Intel Pentium
Processor model	J5005
Processor frequency	1.5 GHz
Processor cores	4
Processor threads	4
Processor lithography	14 nm
Processor boost frequency	2.8 GHz
Processor cache	4 MB
L3 cache	4 MB
Thermal Design Power (TDP)	10 W
Memory bandwidth supported by processor (max)	38.4 GB/s
Processor codename	Gemini Lake
CPU configuration (max)	1
Memory
Memory slots type	SO-DIMM
Number of memory slots	2
Number of DIMM slots	2
Memory channels	Triple-channel
Removable memory card slot	SDXC with UHS-I support
Memory voltage	1.2 V
Supported memory clock speeds	2400 MHz
Supported memory types	DDR4-SDRAM
Memory bandwidth (max)	38.4 GB/s
Maximum internal memory	8 GB
ECC	N
Non-ECC	Y
Storage
Supported storage drive types	HDD & SSD
Storage drive sizes supported	2.5 "
Storage drive interface	Serial ATA III
Number of storage drives supported	1
Card reader integrated	Y
Compatible memory cards	SDXC
Graphics
On-board graphics adapter	N
Graphics adapter family	Intel
On-board graphics adapter model	Intel UHD Graphics 605
Number of displays supported	2
Network
Ethernet LAN	Y
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN controller model	Intel Dual Band Wireless-AC 9462
Bluetooth version	5.0
Bluetooth	Y
Ports & interfaces
USB 2.0 ports quantity	9
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Internal USB 2.0 ports quantity	2
HDMI ports quantity	1
HDMI version	2.0a
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB ports quantity	6
Ethernet LAN (RJ-45) ports	1
S/PDIF out port	Y
Consumer infrared headers	Y
Number of SATA III connectors	1
Graphics output	2x HDMI 2.0a
Expansion slots
PCI Express slots version	2.0
PCI Express configurations	1x4+1x2, 2x1+1x2+1x2, 4x1
Design
Chassis type	UCFF
Product colour	Black
On/off switch	Y
LED indicators	Y
Product type	Mini PC (<= 3L) barebone
ARK ID	214619
Status	Launched
Product family	Intel® NUC Kits
Product series	Intel® NUC Kit with Intel® Pentium® Processors
Product codename	JUNE CANYON
Performance
Motherboard form factor	UCFF
Processor socket	BGA 1090
Number of processors supported	1
Trusted Platform Module (TPM)	N
Audio output channels	7.1 kanalen
Consumer infrared Rx sensor	Y
Windows operating systems supported	Windows 10 x64
Compatible operating systems	Windows 10, 64-bit*
Operating system installed	N
Commodity Classification Automated Tracking System (CCATS)	G157815L2
Harmonized System (HS) code	8471500150
Export Control Classification Number (ECCN)	5A992C
Supported RAID configuration	N/A
Processor special features
Intel® vPro™ Platform Eligibility	N
Execute Disable Bit	Y
Intel® Identity Protection Technology (Intel® IPT)	Y
Intel Virtualization Technology (VT-x)	Y
Intel® Platform Trust Technology (Intel® PTT)	Y
Intel® OS Guard	Y
Intel® Smart Response Technology	N
Intel® Secure Key	Y
Thermal Monitoring Technologies	Y
Intel® Quick Sync Video Technology	Y
Intel® AES New Instructions (Intel® AES-NI)	Y
Intel® Anti-Theft Technology (Intel® AT)	N
Embedded options available	N
Enhanced Intel SpeedStep Technology	Y
Idle States	Y
Intel 64	Y
Intel VT-x with Extended Page Tables (EPT)	Y
Intel Virtualization Technology for Directed I/O (VT-d)	Y
Intel® Hyper Threading Technology (Intel® HT Technology)	N
Intel® Turbo Boost Technology	N
Power
Power supply type	External AC adapter
AC adapter output voltage	12-19 V
Weight & dimensions
Width	115 mm
Depth	111 mm
Height	51 mm
Packaging content
Processor included	Intel® Pentium® Silver J5005 Processor (4M Cache, up to 2.80 GHz)
Other features
Additional headers	CEC, 2x USB2.0, AUX_PWR, FRONT_PANEL
Processor ARK ID	128984
DC input voltage	12 - 19 V
HDD size	2.5
Number of SATA connectors	1
Launch date	Q2'21
