Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.

Max Turbo Frequency
Max Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.

Intel® Rapid Storage Technology
Intel® Rapid Storage Technology provides protection, performance, and expandability for desktop and mobile platforms. Whether using one or multiple hard drives, users can take advantage of enhanced performance and lower power consumption. When using more than one drive the user can have additional protection against data loss in the event of hard drive failure. Successor to Intel® Matrix Storage Technology.

Intel® HD Audio Technology
Intel® High Definition Audio (Intel® HD Audio) is capable of playing back more channels at higher quality than previous integrated audio formats. In addition, Intel® HD Audio has the technology needed to support the latest and greatest audio content.

Integrated Graphics
Integrated graphics allow for incredible visual quality, faster graphic performance and flexible display options without the need for a separate graphics card.

Intel® Optane™ Memory Supported
Intel® Optane™ memory is a revolutionary new class of non-volatile memory that sits in between system memory and storage to accelerate system performance and responsiveness. When combined with the Intel® Rapid Storage Technology Driver, it seamlessly manages multiple tiers of storage while presenting one virtual drive to the OS, ensuring that data frequently used resides on the fastest tier of storage. Intel® Optane™ memory requires specific hardware and software configuration.

TPM
Trusted Platform Module (TPM) is a component on the desktop board that is specifically designed to enhance platform security above-and-beyond the capabilities of today's software by providing a protected space for key operations and other security critical tasks. Using both hardware and software, the TPM protects encryption and signature keys at their most vulnerable stages - operations when the keys are being used unencrypted in plain-text form.

Intel® Platform Trust Technology (Intel® PTT)
Intel® Platform Trust Technology (Intel® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows® 10. Intel® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.

Specification

Product
Product id	863286
Brand	Intel
Partnr	RNUC12SNKI72002#
EAN/UPC code	5032037239691
Warranty (months)	36 months
Processor
Built-in processor	Y
Processor manufacturer	Intel
Processor family	Intel Core i7
Processor model	i7-12700H
Processor generation	Intel Core i7-12xxx
Processor boost frequency	4.7 GHz
Processor cache	24 MB
Memory bandwidth supported by processor (max)	51.2 GB/s
CPU configuration (max)	1
Memory
Memory slots type	SO-DIMM
Number of memory slots	2
Number of DIMM slots	2
Memory channels	Dual-channel
Removable memory card slot	SD Express PCIe G3 NVMe UHS-I
Memory voltage	1.2 V
Supported memory clock speeds	3200 MHz
Supported memory types	DDR4-SDRAM
Memory bandwidth (max)	51.2 GB/s
Maximum internal memory	64 GB
ECC	N
Storage
Supported storage drive types	SSD
Storage drive sizes supported	M.2 "
SSD form factor	M.2
Storage drive interface	PCI Express, Serial ATA III
Number of storage drives supported	3
NVMe	Y
Card reader integrated	Y
Compatible memory cards	SDXC
Graphics
On-board graphics adapter	Y
Graphics adapter family	Intel
On-board graphics adapter model	Intel Iris Xe Graphics
Discrete graphics adapter model	Intel Arc A770M
Graphics adapter memory type	GDDR6
Maximum resolution	5120 x 2880 Pixels
Number of displays supported	4
Audio
Built-in speaker(s)	N
Network
Ethernet LAN	Y
Wi-Fi	Y
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	Wi-Fi 6E (802.11ax)
WLAN controller model	Killer Wi-Fi 6E AX1690
Bluetooth version	5.2
Bluetooth	Y
LAN controller	Intel I225-LM
Ports & interfaces
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	6
HDMI ports quantity	1
HDMI version	2.1
DisplayPorts quantity	1
DisplayPort version	1.4
Combo headphone/mic port	Y
M.2 card slot (wireless)	2230 (E-key)
USB ports quantity	10
M.2 card slot (storage)	3 2280
Ethernet LAN (RJ-45) ports	1
S/PDIF out port	Y
Number of SATA III connectors	1
DC-in jack	Y
Thunderbolt 4 ports quantity	2
Expansion slots
PCI Express slots version	3.0, 4.0
Design
Chassis type	SFF
Product colour	Black
Cooling type	Active
On/off switch	Y
LED indicators	Y
Housing material	Metal, Plastic
Cable lock slot	Y
Cable lock slot type	Kensington
Product type	Mini PC (<= 3L) barebone
Status	Launched
Performance
Number of processors supported	1
Trusted Platform Module (TPM)	N
Audio output channels	7.1 kanalen
Consumer infrared Rx sensor	Y
Windows operating systems supported	Windows 11 x64
Compatible operating systems	Windows 10, 64-bit*
Commodity Classification Automated Tracking System (CCATS)	G157815L2
Export Control Classification Number (ECCN)	5A992C
Processor special features
Intel® vPro™ Platform Eligibility	N
Execute Disable Bit	Y
Intel Trusted Execution Technology	Y
Intel Flex Memory Access	Y
Intel Virtualization Technology (VT-x)	Y
Intel® Platform Trust Technology (Intel® PTT)	Y
Intel® Optane™ Memory Ready	Y
Intel Rapid Storage Technology	Y
Embedded options available	N
Intel VT-x with Extended Page Tables (EPT)	Y
Intel Virtualization Technology for Directed I/O (VT-d)	Y
Intel® High Definition Audio (Intel® HD Audio)	Y
Features
Extended Life Program (XLP)	N
Power
Power supply type	External AC adapter
Power supply	330 W
Number of power supply units	1
AC adapter output voltage	19.5 V
Weight & dimensions
Width	230 mm
Depth	180 mm
Height	60 mm
Other features
Number of SATA connectors	1
Launch date	Q3'22
