Intel® Smart Response Technology

Intel® Smart Response Technology combines the fast performance of a small solid state drive with the large capacity of a hard disk drive.

Hardware Encryption

Hardware encryption is data encryption done at the drive level. This is used to ensure that the data stored on the drive is secured from unwanted intrusion.

End-to-End Data Protection

End-to-End Data Protection ensures integrity of stored data from the computer to the SSD and back.

Intel® Rapid Start Technology

Intel® Rapid Start Technology allows quick system resumes from the hibernate state.

Specification

Product
Product id	612062
Brand	Intel
Partnr	SSDPEKNW010T8X1
EAN/UPC code	5032037131605
Warranty (months)	5 years
Features
SSD form factor	M.2
SSD capacity	1024 GB
Interface	PCI Express 3.0
Memory type	3D2 QLC
NVMe	Y
NVMe version	3.0
Component for	Server/Workstation
Hardware encryption	Y
Security algorithms	256-bit AES
PCI Express interface data lanes	x4
End-to-End Data Protection	Y
Enhanced Power Loss Data Protection technology	N
SSD temperature monitoring	N
Uncorrectable Bit Error Rate (UBER)	< 1 per 10^15 bits read
Mean time between failures (MTBF)	1600000 uur
TBW rating	200
Market segment	Mobile
SSD ARK ID	149407
Harmonized System (HS) code	8471706000
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G158436
Temperature monitoring and logging	N
Power
Power consumption (read)	0.1 W
Power consumption (write)	0.1 W
Power consumption (idle)	0.04 W
Brand-specific features
Intel High Endurance Technology (HET)	N
Intel® Rapid Start Technology	Y
Intel® Remote Secure Erase	N
Intel® Smart Response Technology	Y
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Maximum operating temperature	70 °C
Operating vibration	2.17 G
Non-operating vibration	3.13 G
Operating shock	1000 G
Non-operating shock	1000 G
Operating / non-operating shock	1000 G
Weight & dimensions
Width	22 mm
Depth	80 mm
Weight	10 g
Other features
Processor family	Intel SSD 660p
Internal memory type	PCIe 3.0 x4, NVMe
Sequential reading	1800 MB/s
Sequential writing speed	1800 MB/s
Random read (8GB span)	150000 IOPS
Status	Launched
SSD shock	1000 G
SSD power consumption (idle)	0.040W
Power consumption (active)	0.1 W
Launch date	Q3'18
Random write (8GB span)	220000 IOPS
SSD endurance rating	200 TBW
Product series	Intel® SSD 660p Series
Product codename	Neptune Harbor
