PCIe 5.0 NVMe U.2 for Server Applications
Kingston’s DC3000ME U.2 data center SSD features a high-speed PCIe 5.0 NVMe interface and utilizes 3D eTLC NAND, making it well suited for a wide range of server applications such as AI, HPC, OLTP, databases, cloud infrastructure and edge computing. DC3000ME includes on-board power loss protection to safeguard data in the event of sudden power loss and AES 256-bit encryption for ultimate data security. DC3000ME utilizes the latest high-speed PCIe 5.0 interface and is backward-compatible with PCIe 4.0 servers and backplanes. Like all of Kingston’s data center SSDs, DC3000ME is designed to deliver I/O consistency and low latency as the key design criteria that system integrators, hyperscale data centers and cloud service providers can depend on. DC3000ME is offered in 3.84TB, 7.68TB, 15.36TB and 30.72TB* capacities and is backed by Kingston's legendary technical support and a 5-year limited warranty.

Applications and workloads
DC3000ME is ideal for running a wide range of server applications and workloads including:
- AI
- HPC
- Cloud services
- Edge computing
- Software defined storage
- RAID
- General server use

Enterprise PCIe 5.0 performance
Delivers I/O consistency and low latency with sustained speeds of up to 14, 000MB/s read and 2, 800, 000 read IOPS**.

Optimal storage and efficiency
High capacity options available offering an exceptional balance of consistent I/O delivery and ultra-high performance. Optimized to handle a wide range of server workloads efficiently.

On-board Power Loss Protection (PLP)
Enterprise-class protection to reduce possibility of data loss or corruption on ungraceful power fails including NVMe-MI 1.2b out-of-band management, end-to-end data protection, TCG Opal 2.0.

AES 256-bit encryption
Secure sensitive data with AES 256-bit hardware-based encryption and TCG Opal 2.0.

Specification

Product
Product id	1019098
Brand	Kingston Technology
Partnr	SEDC3000ME/30T7
EAN/UPC code	740617354843
Warranty (months)	Limited 5-year warranty with free technical support
Features
SSD form factor	U.2
SSD capacity	30720 GB
Interface	PCI Express 5.0
Memory type	3D eTLC
NVMe	Y
Component for	Server
Hardware encryption	Y
Security algorithms	256-bit AES, TCG Opal 2.0
Read speed	14000 MB/s
Write speed	9700 MB/s
Random read (4KB)	2600000 IOPS
Random write (4KB)	350000 IOPS
Read latency	175 µs
Write latency	12 µs
Power loss protection	Y
Mean time between failures (MTBF)	2000000 uur
TBW rating	56064
Market segment	Server
Power
Power consumption (read)	9.5 W
Power consumption (write)	24 W
Power consumption (idle)	9 W
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Non-operating vibration	10 G
Weight & dimensions
Width	69.8 mm
Depth	100.5 mm
Height	14.8 mm
Weight	160.5 g
Packaging data
Package width	129.54 mm
Package depth	16.76 mm
Package height	184.15 mm
Package weight	189.14 g
Logistics data
Country of origin	Taiwan
Master (outer) case width	135.89 mm
Master (outer) case length	203.2 mm
Master (outer) case height	69.85 mm
Master (outer) case weight	1212.84 g
Quantity per master (outer) case	6 stuk(s)
