Accurate and Vivid Colors
Featuring self-lighting pixels, the display maintains vivid colors and high contrast ratio even when the display becomes transparent. It brings content to life from wide viewing angles, and the content blends into its surroundings seamlessly and naturally.

Intuitive P-Cap Touch
By adding P-Cap touch sensor film to the display, the utilization possibilities expand to various industries where customer interaction services are demanding. Users could enjoy its fascinating content using their fingertips.

High Transparency
LG’s OLED technology makes the Transparent OLED Touch Signage have slimmer structure without backlight unit nor a liquid crystal layer, achieving high transparency even with P-Cap touch film. While clearly showing objects behind the screen, it overlays the relevant information right before them.

Protective Tempered Glass
Touching a display directly can cause damage or scratches. The tempered front glass protects product from such external impacts and its anti-shatter glass is designed to minimize customers’ injuries.

Enhanced Spatial Versatility
Experience the extraordinary with the state-of-the-art LG Transparent OLED Signage, which breaks down the barriers between the screen and surrounding environment, seamlessly connecting different spaces and people.

Specification

Product
Product id	1005740
Brand	LG Electronics
Partnr	30EW5TP-A
EAN/UPC code	8806096114650
Warranty (months)	24 months
Display
Display diagonal	30 inch
LED backlight	Y
Display resolution	1366 x 768 Pixels
Display brightness	600 cd/m²
HD type	HD
Touchscreen	Y
Touchscreen technology	Projected capacitive system
Native aspect ratio	16:9
Response time	8 ms
Contrast ratio (typical)	200000:1
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	1.073 billion colours
Panel life	30000 uur
Haze rate	3 procent
Panel type	OLED
Glass thickness	3 mm
Transparency	37 procent
Ports & interfaces
HDMI ports quantity	1
HDMI input ports quantity	1
DVI port	N
DisplayPorts quantity	2
DisplayPorts in	1
DisplayPorts out	1
USB port	Y
Ethernet LAN	Y
USB 2.0 Type-B ports quantity	3
Ethernet LAN (RJ-45) ports	2
Audio (L/R) out	1
RS-232C	Y
Remote (IR) input	1
Remote (IR) output	1
Design
Design	Digital signage flat panel
Product colour	Silver
Placement supported	Indoor
Orientation	Horizontal/Vertical
Screen shape	Flat screen
Bezel width (top)	7.9 mm
Bezel width (side)	7.9 mm
Bezel width (bottom)	114.7 mm
Performance
Purpose	Commercial
On Screen Display (OSD)	Y
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, TUR
Operating hours (hours/days)	18/7
HDCP	Y
HDCP version	1.4/2.2
Power
Power consumption (typical)	45 W
Power consumption (standby)	0.5 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Heat dissipation	154 BTU/h
Computer system
Internal memory	16 GB
Windows operating systems supported	Windows 10, Windows 11
Weight & dimensions
Display width	680.2 mm
Base depth	42.8 mm
Display depth	15.3 mm
Base height	288.6 mm
Display height	496.2 mm
Display weight	4200 g
Base width	449.2 mm
Base weight	2400 g
Width (with stand)	449.2 mm
Packaging data
Package width	826 mm
Package depth	195 mm
Package height	593 mm
Package weight	10100 g
Packaging content
Handheld remote control	Y
Cables included	HDMI, Power, USB
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 procent
Features
Heat dissipation (max)	294 BTU/h
Other features
Display technology	OLED
Power consumption (max)	86 W
