Customizable Open-frame Display for Smart Effciency

Open-frame Outdoor Display
LG Open Frame display empowers you to personalize not only the casing design but also the function, granting you the freedom to tailor the display to your exact preferences.

High Visibility Under
Strong Sunlight
With outstanding high brightness of 3, 000 nits (Typ. ), the XF3P outdoor display delivers content clearly while captivating passerby. In addition, its outdoor visibility can deliver a variety of information even to those wearing polarized sunglasses.

Optimized Design for Double-sided Display
The XF3P, featuring a sleeker design than the conventional model, excels in maximizing space efficiency with its convenient double-sided display.

Efficient Energy Management
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management. Also, XF3P uses M+ panel that can offer high energy efficiency and cost savings by decreasing power consumption.

High-performance with webOS 6.0
Quad Core SoC (System-on-Chip) can execute several tasks at the same time without a separate media player. In addition, webOS 6.0 platform enhances not only user convenience with intuitive UI but also web-app integration with updated Node JS / Chromium version.

Wide Range of Operating Temperature
The XF3P can be used under a wide range of operating temperature from 0℃ to 50℃.

Conformal Coating
Conformal Coating protects the circuit board and power board against dust, iron powder, humidity, etc.

Installation Guide for a Customized Casing
LG offers an installation guide for designing a customized casing to ensure stable performance for outdoor displays. It includes information about the size of ventilation and the location of partitions within the casing.

Web Monitoring
The LG Control Manager, the embedded web monitoring program, is user-friendly and enables the user to have full access anywhere at anytime from their mobile phone or PC while having access to both current and past data. It allows the user to monitor the unit, make adjustments, and control the unit remotely in real time.

Professional Content Partners
Pairing the XF3P with LG SW solutions would enhance its utilization.

Specification

Product
Product id	1004844
Brand	LG Electronics
Partnr	75XF3P-B
EAN/UPC code	8806096069981
Warranty (months)	24 months
Display
Display diagonal	75 inch
Display resolution	3840 x 2160 Pixels
Display brightness	3000 cd/m²
HD type	4K Ultra HD
Native aspect ratio	16:9
Response time	8 ms
Contrast ratio (typical)	1200:1
Contrast ratio (dynamic)	500000:1
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	1.07 billion colours
Panel life	50000 uur
Native refresh rate	60 Hz
Haze rate	3 procent
Panel type	IPS
Ports & interfaces
HDMI ports quantity	2
DVI port	Y
DVI-D ports quantity	1
DisplayPorts quantity	1
DisplayPorts in	1
DisplayPorts out	1
USB port	Y
USB ports quantity	1
USB version	2.0
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	1
Audio (L/R) in	1
Audio (L/R) out	1
RS-232C	Y
Remote (IR) input	1
Design
Design	Digital signage flat panel
Product colour	Black
Orientation	Horizontal/Vertical
Bezel colour	black
Performance
Purpose	Commercial
On Screen Display (OSD)	Y
Number of OSD languages	22
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, TUR
HDCP	Y
HDCP version	1.3
Power
Power consumption (typical)	745 W
Power consumption (off)	0.5 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Heat dissipation	2.644 BTU/h
Computer system
Computer system	Y
Computer system type	System on Chip (SoC)
Processor cores	2
Internal memory	8 GB
Weight & dimensions
Display width	1675.2 mm
Display depth	114.6 mm
Display height	953.6 mm
Display weight	32700 g
Packaging data
Package width	1816 mm
Package depth	285 mm
Package height	1106 mm
Package weight	43000 g
Packaging content
Handheld remote control	Y
Cables included	HDMI, Power
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 80 procent
Certificates
Certification	CB / NRTL, ErP, FCC Class "A" / CE / KC / VCCI
Features
Suitable for indoor use	Y
Technical details
Compliance certificates	CB, CE, KC, VCCI
Sustainability certificates	ErP
Other features
USB connector type	USB Type-A
Power consumption (max)	775 W
