Product |
Product id
| 553226
|
Brand
| NEC
|
Partnr
| 100014160
|
EAN/UPC code
| 5028695612389
|
Features |
Type
| AV transmitter & receiver
|
Cable types supported
| Cat5e, Cat6
|
Maximum transfer distance
| 30 m
|
LED indicators
| Y
|
Supported video modes
| 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
|
Supported graphics resolutions
| 640 x 480 (VGA), 1920 x 1200 (WUXGA)
|
HDCP
| Y
|
Product colour
| White
|
HDBaseT certified
| Y
|
Certification
| CE, FCC, EAC, SASO
|
Ports & interfaces |
Ethernet LAN
| Y
|
RJ-45 input ports
| 2
|
RJ-45 output ports
| 1
|
HDBaseT port
| Y
|
Number of HDMI outputs
| 1
|
HDMI in
| 3
|
USB ports quantity
| 4
|
USB version
| 2.0
|
USB connector type
| USB Type-A, USB Type-B
|
RS-232 output ports
| 1
|
Remote (IR) input
| 1
|
RS-232 input ports
| 1
|
Power |
AC input voltage
| 100-240 V
|
AC input frequency
| 50/60 Hz
|
Input current
| 1.4 A
|
Power consumption (typical)
| 21 W
|
Operational conditions |
Operating temperature (T-T)
| 5 - 40 °C
|
Storage temperature (T-T)
| 10 - 50 °C
|
Operating relative humidity (H-H)
| 20 - 80 procent
|
Storage relative humidity (H-H)
| 20 - 80 procent
|
Weight & dimensions |
Weight
| 500 g
|
Receiver dimensions (W x D x H)
| 126 x 52 x 119 mm
|
Transmitter dimensions (WxDxH)
| 285 x 64 x 187 mm
|
Package dimensions (WxDxH)
| 354 x 175 x 333 mm
|
Packaging content |
AC adapter included
| Y
|
Cables included
| HDMI, RS-232
|
Manual
| Y
|
Mounting kit
| Y
|
Technical details |
Colour depth
| 12 Bit
|
RoHS compliance
| Y
|
