Your meeting room companion
NEC’s InfinityBoard is a powerful and scalable workspace that is designed to fit any meeting scenario. Brainstorming, reviewing, video conferencing or collaborating, whatever the objectives of your meeting, the InfinityBoard is the modular solution that’s here to help create your ideal meeting space.

Designed to ‘just work’, the InfinityBoard supports any scenario – from multiple presenters to large groups with remote participation. In virtual workspaces, collaboration lifts to a new level and interactive meetings boost group work efficiency.

The InfinityBoard comes with an ultra-high definition InGlass™ touch display and two passive pens. Its design also includes an ultra-wide angle Huddly IQ video conferencing camera and high-end conference speakers. The combination of an open platform slot-in PC and Windows 10 Professional allows to tailor the solution according to the customers' requirements without restriction to any particular software, video conferencing app or infrastructure. Quicklaunch™ is a simple and secure meeting room interface that provides multi-platform integration to transform the InfinityBoard into a one-click meeting space.

Specification

Product
Product id	705999
Brand	NEC
Partnr	40001445
EAN/UPC code	5028695119932
Warranty (months)	3 years
Technical details
Product type	Group video conferencing system
Bluetooth	Y
Bluetooth version	4.2
Product colour	Black
Harmonized System (HS) code	85176990
Performance
Wall mountable	Y
Video
HD type	Full HD
Digital zoom	3 x
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
Maximum frame rate	30 fps
Aspect ratio	16:9
Video formats supported	FLV, MOV, MP4, MPG, WMV
Resolution at capture speed	1920x1080@30fps
Image formats supported	JPG, PNG
Audio
Frequency range	70 - 15000 Hz
Line-out impedance	8 Ohm
RMS rated power	40 W
Audio formats supported	MP3, WAV
Memory
Internal memory	16384 MB
Internal memory type	DDR4
Storage media type	SSD
Total storage capacity	256 GB
Memory card slot(s)	Y
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Ports & interfaces
HDMI ports quantity	3
USB connector type	USB Type-A, USB Type-B
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
Headphone outputs	1
Fast Ethernet (copper) ports quantity	2
Serial interface type	RS-232
RS-232 ports	1
Network
Ethernet LAN	Y
Ethernet LAN data rates	100 Mbit/s
Wi-Fi	Y
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Camera
Horizontal field of view	120 °
Vertical field of view	90 °
Diagonal field of view	150 °
Display
Built-in display	Y
Display	IPS
Display diagonal	86 inch
Display resolution	3840 x 2160 Pixels
Touchscreen	Y
Contrast ratio (typical)	1200:1
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display brightness	500 cd/m²
Anti-glare screen	Y
Colour depth	10 Bit
Computer system
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP
Mac operating systems supported	Y
VESA mounting	Y
Mobile operating systems supported	Y
Operational conditions
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 procent
Power
Power consumption (max)	242 W
Weight & dimensions
Width	2192 mm
Depth	86 mm
Height	1142 mm
Weight	91700 g
Package width	2157 mm
Package depth	1290 mm
Package height	320 mm
Package weight	98000 g
Packaging content
Cables included	AC, DisplayPort, USB
Manual	Y
Camera included	Y
Handheld remote control	Y
