When imaging precision cannot be compromised
When imaging precision and 24/7 operational reliability cannot be compromised, the 5th generation of NEC MultiSync P series presents best-in-class performance with an advanced feature set for mission-critical applications.

Even in bright ambient light conditions, high brightness levels of 700 cd/m² combined with a high haze filter guarantees exceptional readability with no annoying reflections. Despite its slim, elegant profile, the quality build is robust for use in public spaces, with an all-metal chassis for fire-retardancy. Featuring the pre-installed NEC MediaPlayer you get an out of the box signage experience and can playback the content needed for your application: video, picture, html or use any of the supported Content Management Systems (CMS).

For best visualisation in control rooms and production lines, for passenger information and wayfinding signage; the NEC P-MPi4 series is trusted for safety and long-life, fit-for-purpose performance. .

Specification

Product
Product id	720525
Brand	NEC
Partnr	60005377
EAN/UPC code	5028695122598
Display
Display diagonal	49 inch
LED backlighting type	Edge-LED
Display resolution	3840 x 2160 Pixels
Display brightness	700 cd/m²
HD type	4K Ultra HD
Native aspect ratio	16:9
Response time	8 ms
Contrast ratio (typical)	8000:1
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	1.073 billion colours
Display diagonal (metric)	124.5 cm
Native refresh rate	60 Hz
Haze rate	28 procent
Horizontal scan range	15 - 135 kHz
Vertical scan range	23 - 76 Hz
Ports & interfaces
HDMI ports quantity	3
HDMI input ports quantity	2
HDMI output ports quantity	1
DisplayPorts quantity	3
DisplayPorts in	2
DisplayPorts out	1
USB port	Y
USB ports quantity	3
USB version	2.0
Ethernet LAN	Y
Ethernet LAN data rates	100 Mbit/s
Number of speaker outputs	1
RS-232 interface	Y
Remote (IR) input	1
Design
Design	Digital signage flat panel
Product colour	Black
Placement supported	Indoor
Orientation	Horizontal/Vertical
VESA mounting	Y
Panel mounting interface	300 x 300 mm
Bezel width (top)	12 mm
Bezel width (side)	12.5 mm
Bezel width (bottom)	15.6 mm
Performance
Purpose	Universal
Ambient light sensor	Y
Operating hours (hours/days)	24/7
HDCP	Y
International Protection (IP) code	IP5X, IP2X
Power
Power consumption (typical)	105 W
Power consumption (standby)	0.5 W
Energy efficiency class (SDR)	G
AC input voltage	100 - 240 V
Energy efficiency class (HDR)	G
AC input frequency	50 - 60 Hz
Energy consumption (SDR) per 1000 hours	106 kWu
Energy consumption (HDR) per 1000 hours	98 kWu
Energy efficiency scale	A to G
Computer system
Computer system	Y
Computer system type	System on Chip (SoC)
Built-in processor	Y
Processor family	ARM Cortex
Processor model	A72
Processor frequency	1.5 GHz
Internal storage capacity	32 GB
Weight & dimensions
Display width	1103.4 mm
Display depth	61.1 mm
Display height	636.2 mm
Display weight	22900 g
Packaging data
Package width	1298 mm
Package depth	224 mm
Package height	860 mm
Package weight	29800 g
Packaging content
Handheld remote control	Y
Batteries included	Y
Cables included	AC, HDMI
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 procent
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	10 - 90 procent
Features
Harmonized System (HS) code	85285210
Technical details
Sustainability certificates	ENERGY STAR
Other features
Display technology	IPS
