Digital signage and real-time information deployed easily

Initiating effective communication to your target audience has never been easier to plan, install and operate. Deploying Signage with consistently updated information, real-time content adaption and scheduling has never been so simple. The MultiSync M-MPi4 displays provide a sleek combination of intuitive media playback with professional digital display technology for impactful messaging in retail environments, leisure and museum applications as well as quick service restaurants. Fitting perfectly into corporate environments and public spaces, the modern, slim design integrates seamlessly with the surrounding architecture whilst the 500 cd/m² brightness output and anti-glare surface ensures excellent viewing. Future-proof and upgradable, the NEC MediaPlayer software is powered by a pre-installed modular SoC Raspberry Pi module. Enabling remote operation of single and multiple display installations, benefit from flexible usage of many media types and a scheduling function for smart content management. For specific feature demands, the NEC MediaPlayer grants easy switching to the integrated Content Management Systems directly.

Benefits

- Modern and slim design – robust yet elegant allowing for an unobtrusive integration into any application and environment.
- Intuitive Plug & Play solution – even when not familiar with using digital signage, users can facilitate stunning signage creation for immersive real-time visual experiences
- Install third party software – expand the NEC MediaPlayer functionality via additional Apps or even switch to your preferred Content Management Systems (CMS) directly from of the NEC MediaPlayer
- Everything under control – one single interface is needed to manage both the NEC MediaPlayer and the display directly, via a web-interface or the NEC Display remote control.
- Unhindered readability – no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation

Specification

Product
Product id	720520
Brand	NEC
Partnr	60005382
EAN/UPC code	5028695122499
Warranty (months)	3 years
Display
Display diagonal	55 inch
LED backlighting type	Edge-LED
Display resolution	3840 x 2160 Pixels
Display brightness	500 cd/m²
HD type	4K Ultra HD
Native aspect ratio	16:9
Response time	8 ms
Contrast ratio (typical)	8000:1
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display diagonal (metric)	139 cm
Native refresh rate	60 Hz
Haze rate	28 procent
Horizontal scan range	26 - 91.1 kHz
Panel type	IPS
Vertical scan range	23 - 86 Hz
Ports & interfaces
HDMI ports quantity	2
DisplayPorts quantity	1
USB port	Y
USB ports quantity	1
Ethernet LAN	Y
Ethernet LAN (RJ-45) ports	1
Ethernet LAN data rates	100 Mbit/s
RS-232 interface	Y
Design
Product colour	Black
Placement supported	Indoor
Orientation	Horizontal/Vertical
VESA mounting	Y
Panel mounting interface	300 x 300 mm
Bezel width (top)	12 mm
Bezel width (side)	12.5 mm
Bezel width (bottom)	15.6 mm
Mounting type	Wall
Performance
Purpose	Commercial
Ambient light sensor	Y
Operating hours (hours/days)	24/7
HDCP	Y
International Protection (IP) code	IP5X, IP2X
Power
Power consumption (typical)	110 W
Power consumption (standby)	2 W
Energy efficiency class (SDR)	G
Energy efficiency class (HDR)	G
Energy consumption (SDR) per 1000 hours	100 kWu
Energy consumption (HDR) per 1000 hours	90 kWu
Computer system
Built-in processor	Y
Processor family	ARM Cortex
Processor model	A72
Processor frequency	1.5 GHz
Internal memory	32 GB
Video formats supported	AVI, H.265, M4V, MKV, MOV, MP4, MPEG, MPEG2, MPG, VOB, VP8, VP9, WMV
Audio formats supported	AAC, AC3, MP3
Image formats supported	JPEG, JPG, PNG
Weight & dimensions
Display width	1239.6 mm
Display depth	61.1 mm
Display height	713 mm
Display weight	26400 g
Packaging data
Package width	1430 mm
Package depth	250 mm
Package height	920 mm
Package weight	36470 g
Packaging content
Handheld remote control	Y
Batteries included	Y
Cables included	AC, HDMI
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 procent
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	10 - 90 procent
Features
Harmonized System (HS) code	85285210
Technical details
Sustainability certificates	ENERGY STAR
Other features
Display technology	LCD
