The X-Series durable displays are designed for reliable 24/7 operation in the demanding environments. With the selectable gamma curves and versatile connectivity, the enhanced X-Series provides an optimal visual experience with excellent colour, brightness, and contrast ratio. NeoV™ Optical Glass and metal casing shield it from scratches and other damages which make it ideal for public, retail, laboratory, and industrial applications.

Enhanced Gamma Correction
Selectable gamma curves visually optimise different kinds of images. The AG Neovo specialised image settings enhance colour, brightness, sharpness and contrast ratio, allowing the X-Series to improve the light, shadows and colour balance of videos.

Versatility, Productivity and Compatibility
Visualize critical data and engage with multiple video sources and PC applications with versatile connectivity options, including DisplayPort and HDMI, and PIP/PBP to increase productivity and effciency. Selectable aspect ratio and zoom functions provide compatibility with different video sources.

High Reliability
Designed for 24/7 operation, these durable metal-housed displays protected with NeoV™ Optical Glass take advantage of superior components to ensure a long product lifetime.

Specification

Product
Product id	601959
Brand	AG Neovo
Partnr	X-15E
EAN/UPC code	4710739594881
Network
Wi-Fi	N
Bluetooth	N
Technical details
Sustainability certificates	RoHS
Compliance certificates	RoHS
Native refresh rate	60 Hz
Display
Display diagonal	15 inch
Display resolution	1024 x 768 Pixels
Native aspect ratio	4:3
Panel type	TFT
Display brightness (typical)	300 cd/m²
Response time	5 ms
HD type	XGA
Display technology	LCD
Backlight type	LED
Display surface	Matt
Screen shape	Flat screen
Supported graphics resolutions	1024 x 768 (XGA)
Contrast ratio (typical)	2000:1
Contrast ratio (dynamic)	20000000:1
Viewing angle, horizontal	176 °
Viewing angle, vertical	176 °
Display number of colours	16.2 million colours
3D	N
Pixel pitch	0.297 x 0.297 mm
Horizontal scan range	15 - 81 kHz
Vertical scan range	50 - 85 Hz
Digital horizontal frequency	24 - 83 kHz
Digital vertical frequency	50 - 75 Hz
Surface hardness	9H
NTSC coverage (typical)	72 procent
Colour gamut standard	NTSC
Performance
NVIDIA G-SYNC	N
AMD FreeSync	N
Multimedia
Built-in speaker(s)	Y
Built-in camera	N
Number of speakers	2
RMS rated power	2 W
Design
Product colour	Black
Housing material	Metal
Certification	CB, CE, WEEE, REACH, EuP/Erp
Ports & interfaces
Built-in USB hub	N
VGA (D-Sub) ports quantity	1
DVI port	Y
DVI-D ports quantity	1
HDMI	Y
HDMI ports quantity	1
HDMI version	1.4
DisplayPorts quantity	1
DisplayPort version	1.2a
Audio input	Y
PC Audio in	Y
DC-in jack	Y
Ergonomics
VESA mounting	Y
Panel mounting interface	75 x 75, 100 x 100 mm
Cable lock slot	Y
Cable lock slot type	Kensington
Tilt angle range	0 - 20 °
Picture-in-Picture	Y
Tilt adjustment	Y
Plug and Play	Y
Thin Client
Thin client installed	N
Packaging data
Stand included	Y
Cables included	AC, Audio (3.5mm), VGA
Quick start guide	Y
Package width	470 mm
Package depth	199 mm
Package height	460 mm
Package weight	5800 g
Package type	Box
Power
Energy efficiency class (SDR)	D
Energy consumption (SDR) per 1000 hours	9.7 kWu
Power consumption (typical)	12 W
Energy efficiency class (HDR)	Not available
Power consumption (standby)	0.5 W
Power consumption (off)	0.5 W
Energy efficiency scale	A to G
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	10 - 90 procent
Storage relative humidity (H-H)	5 - 90 procent
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12192 m
Weight & dimensions
Width (with stand)	380 mm
Depth (with stand)	155 mm
Height (with stand)	359 mm
Weight (with stand)	4600 g
Weight (without stand)	4200 g
Logistics data
Harmonized System (HS) code	85285210
Other features
AC adapter included	Y
On/off switch	Y
TV tuner integrated	N
Power supply type	External
Touchscreen	N
Ethernet LAN	N
Supplied AC adapter type	LCD
