EASY POE CONTROLS

Manage PoE prioritization, PoE power limit per port, PoE scheduling and more for advanced control over all PoE-powered devices

GIGABIT ETHERNET

5 ports provide gigabit Ethernet connectivity to your devices

VLANS

Port-based and 802.1Q-based network separation into smaller groups for more secure and efficient use of network resources

FANLESS DESIGN

Silent operation makes this switch perfect for noise-sensitive environments

VERSATILE MOUNTING OPTIONS

Place your switch on your desktop or mount it to your wall with the hardware provided in the box. Silent operation makes this switch perfect for noise-sensitive environments

ENERGY EFFICIENT

Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption when there is light traffic on an active port or when there is no link or no activity detected

Specification

Product
Product id	993214
Brand	Netgear
Partnr	GS105EP-100EUS
EAN/UPC code	606449174670
Data transmission
MAC address table	2000 entries
Jumbo frames support	Y
Jumbo frames	9216
Packet buffer memory	1.5 MB
Network
Networking standards	IEEE 802.1p, IEEE 802.3az
Port mirroring	Y
Full duplex	Y
Flow control support	Y
Rate limiting	Y
Virtual LAN features	Port-based VLAN
Management features
Switch type	Unmanaged
Quality of Service (QoS) support	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	5
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Security
DHCP features	DHCP client
IGMP snooping	Y
Queue scheduling algorithms	Strict Priority Queue (SPQ), Weighted Round Robin (WRR)
Password protection	Y
Weight & dimensions
Width	158 mm
Depth	101 mm
Height	27 mm
Weight	390 g
Packaging data
Quick start guide	Y
Manual	Y
Power
Power source	AC/DC
Power consumption (typical)	4 W
Power consumption (max)	74.7 W
Multicast features
Multicast support	Y
Number of multicast groups filtered	128
Endurance
Mean time between failures (MTBF)	1164104 uur
Design
Stackable	N
Product colour	Grey
Housing material	Metal
LED indicators	Activity, Link, PoE, Power, Speed, System
Operational conditions
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	0 - 95 procent
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 procent
Technical details
Compliance certificates	BSMI, CE, Federal Communications Commission (FCC), KC, VCCI
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet plus (PoE+) ports quantity	4
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	63 W
Other features
Connectivity technology	Wired
