More Capabilities beyond Plug-and-play Connectivity

Today's growing businesses are both placing more demands on and relying more on their network. Companies are putting more applications and demands on their Ethernet Infrastructure. Using VoIP phones and IP cameras require more than simple plug-and-play connectivity. Additionally, Internet-based applications such as Hotmail and Google Calendaring have made keeping the network up a business-critical need. However, companies do not necessarily have more money or advanced training to deal with complex managed switches. NETGEAR's new ProSafe Plus Switches meet this growing need by providing easy to use visibility and limited confi guration capabilities. To provide more insight into the network behavior, ProSafe Plus Switches offer traffic monitoring for users to observe traffic behavior. Additionally, if there are connectivity issues, these switches offer a cable diagnostic test capability that can identify and even locate problems in the cables. To optimize traffic through the switches, ProSafe Plus Switches offer both port and tag-based prioritization to keep latency-sensitive traffic moving ahead of less critical packets. Also, as a means of improving security or managing collision domains, ProSafe Smart Switches offer VLAN technology. ProSafe Plus Switches offering these monitoring and confi guration capabilities at a slight cost premium over un anaged switches, delivering great value to the end user.

Additionally, furthering NETGEAR's support of the environment, ProSafe Plus Switches have power-saving Green Ethernet technology. The GS108E switch comes in a sturdy metal case with a fan-less design for silent operation.

NETGEAR Green

- Up to 60% lower power consumption than the non-Green version;
- Auto power-down and cable-length detection for energy savings;
- Packaging manufactured with at least 80% recycled materials.

Specification

Product
Product id	993215
Brand	Netgear
Partnr	GS108EP-100EUS
EAN/UPC code	606449174632
Data transmission
MAC address table	4000 entries
Jumbo frames support	Y
Jumbo frames	9216
Packet buffer memory	1.5 MB
Network
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3az
Port mirroring	Y
Flow control support	Y
Rate limiting	Y
VLAN support	Y
Virtual LAN features	Port-based VLAN
Number of VLANs	64
Port trunking	Y
Management features
Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Security
DHCP features	DHCP client
IGMP snooping	Y
Queue scheduling algorithms	Priority queuing (PQ), Strict Priority Queue (SPQ), Weighted Round Robin (WRR)
Password protection	Y
Weight & dimensions
Weight	522 g
Power
Power source	AC/DC
Multicast features
Number of multicast groups filtered	128
Endurance
Mean time between failures (MTBF)	859126 uur
Design
Product colour	Grey
Housing material	Metal
LED indicators	Activity, Link, PoE, Power, Speed, System
Operational conditions
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	0 - 95 procent
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 procent
Technical details
Compliance certificates	BSMI, CE, Federal Communications Commission (FCC), KC, VCCI
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
Power over Ethernet plus (PoE+) ports quantity	8
Total Power over Ethernet (PoE) budget	62 W
Other features
Connectivity technology	Wired
Bandwidth	16 Gbit/s
