NETGEAR GS324TPv2. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 16000 entries, Switching capacity: 52 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE. . . . Power over Ethernet (PoE). Rack mounting, Form factor: 1U

Specification

Product
Product id	1009476
Brand	Netgear
Partnr	GS324TP-200EUS
EAN/UPC code	606449175950
Data transmission
MAC address table	16000 entries
Switching capacity	52 Gbit/s
Store-and-forward	Y
Jumbo frames support	Y
Packet buffer memory	1.5 MB
Network
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Port mirroring	Y
Full duplex	Y
Flow control support	Y
Auto-negotiation	Y
Spanning tree protocol	Y
Rate limiting	Y
Broadcast storm control	Y
Link aggregation	Y
VLAN support	Y
Virtual LAN features	Port-based VLAN, Private VLAN, Voice VLAN
Number of VLANs	256
Management features
Switch type	Managed
Switch layer	L2/L3
Quality of Service (QoS) support	Y
Web-based management	Y
ARP inspection	Y
MIB support	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP module slots quantity	2
Security
DHCP features	DHCP client
Access Control List (ACL)	Y
IGMP snooping	Y
Loop protection	Y
Weight & dimensions
Width	440 mm
Depth	253 mm
Height	43 mm
Weight	3530 g
Packaging data
Quick start guide	Y
User guide	Y
Manual	Y
Power
Power source	PoE
Multicast features
Multicast support	Y
Design
Rack mounting	Y
Form factor	1U
Product colour	Black
LED indicators	Y
Number of fans	2 ventilator(en)
Operational conditions
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	0 - 95 procent
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 procent
Performance
Built-in processor	Y
Processor frequency	800 MHz
Memory type	RAM
Internal memory	512 MB
Flash memory	64 MB
Noise level	26.1 dB
Technical details
Shipping (inner) case height	380 mm
Warranty period	3 jaar
Quantity per shipping (inner) case	2 stuk(s)
Shipping (inner) case net weight	10870 g
Shipping (inner) case length	241 mm
Shipping (inner) case width	567 mm
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet plus (PoE+) ports quantity	24
Total Power over Ethernet (PoE) budget	190 W
