Industry’s most powerful Wireless 802.11AC Wave 2 tri-band Access Point with NETGEAR Insight management
One of the most problematic situations for any network owner/manager is when the infrastructure runs out of resources and bandwidth and forklift upgrades are needed to remedy the situation. Not any more with The NETGEAR® AC3000 Tri-band WiFi Business Access Point WAC540. It is a sophisticated access point with 3 radios that can handle any situation where there are large number of WiFi clients demanding service. Office locations with hundreds of employees with multiple devices (laptop, notepad and smart phones) can enjoy WAC540’s performance and coverage together with the ease of use that comes with Insight to overcome all demanding situations when designing and provisioning networks.

Advanced features such as port aggregation together with PoE power allows WAC540 to utilize a bundled gigabit Ethernet for backhaul when powered via Ethernet PoE ports while dedicating its 5G 4x4 radio for servicing even more clients.

Whether your business requires the WiFi network to support the users with office and CRM and instant messaging tools, handling VoIP calls or hosting live video on smart WiFi TVs around the office, WAC540 has the power to keep all of these applications running smoothly.

Finally, the WAC540 is managed by NETGEAR Insight, for a more intuitive and innovative support, with no need for extra management hardware from anywhere through a smart device such as a phone, tablet or a laptop.

Where to use Access Point
- College Campuses
- Hotels
- Small Airports
- Large Office Spaces

INSTANT MESH

One WiFi network. Maximum WiFi Expansion.

Connect multiple areas without the use of cables with NETGEAR WAC540 or WAC564.

Both devices have three robust 802.11ac radios to establish a strong wireless backhaul link to a nearby Instant Mesh device.

Remote monitoring and management with NETGEAR Insight
- Instant discovery & set-up
- Local and Cloud monitoring and management through the Insight app or Cloud Portal
- Remote access and multi-device configuration
- No additional Cloud controller, appliance, network manager, or PC/server is necessary
- QR code intial configuaration for instant installation

Specification

Product
Product id	648021
Brand	Netgear
Partnr	WAC540B03-10000S
EAN/UPC code	606449128611
Warranty (months)	5 Years
Management features
Web-based management	Y
Packaging data
Number of products included	3 stuk(s)
Mounting kit	Y
Features
2.4 GHz	Y
5 GHz	Y
Maximum data transfer rate	1733 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Throughput data rate	3000 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11v, IEEE 802.1x, IEEE 802.3at
Number of users	600 gebruiker(s)
Auto MDI/MDI-X	Y
MIMO	Y
MIMO type	Multi User MIMO
Modulation	256-QAM
Fit AP mode features	802.11k & 802.11v smart roaming, Wireless distribution system (WDS)
Wi-Fi Multimedia (WMM)/(WME)	Y
Wi-Fi roaming	Y
WLAN channel features	WLAN channel management
VLAN support	Y
Adaptive bandwidth management	Y
Band steering	Y
Airtime Fairness (ATF)	Y
Security
Security algorithms	EAP-TLS, PEAP, SNMP, SSH, SSID, SSL/TLS, TTLS, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA2-PSK
MAC address filtering	Y
Service Set Identifier (SSID) features	SSID broadcast on/off
Auto Wireless Distribution System (WDS)	Y
Remote Authentication Dial-In User Service (RADIUS)	Y
Access Control List (ACL)	Y
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
DC-in jack	Y
Power
Power over Ethernet (PoE)	Y
AC input voltage	12 V
Input current	2.5 A
Power consumption (typical)	25.5 W
Design
Placement	Ceiling, Wall
Product colour	White
Reset button	Y
LED indicators	LAN, Power, WLAN
Antenna
Antenna type	Internal
Antenna features	Integrated antenna
Antenna gain level (max)	4 dBi
Weight & dimensions
Width	241.53 mm
Depth	241.53 mm
Height	40.21 mm
Weight	752 g
