Get powerful and reliable WiFi 6 connectivity for all your devices, even in high-density environments. Simplified enterprise-grade security and networking for small and medium sized business.

REMOTE CLOUD MANAGEMENT
Plug-and-play set up and remote management of small business networks

NETWORK TOPOLOGY
A single, holistic view of wired and wireless networks for further troubleshooting

HIGH-DENSITY WIFI MANAGEMENT
Deep wireless management features with more tools to deploy small and large WiFi networks

Business-Level Security
WPA3 for the highest level of WiFi connection security

8 Wireless Networks (SSIDs)
Separate VLANs and WPA3 makes WAX630 the ideal network configuration for SMBs for security and manageability

Separate VLANs
Keep admin, employee, visitor, HR, Finance department networks safely separated from each other
NETGEAR INSIGHT FOR VARS
Multi-location & multi-tenant remote network management from a single pane-of-glass

Easy Setup
Set up, configure, and manage with NETGEAR Insight

Remote Management
Remote Cloud monitoring and management with NETGEAR Insight for single pane of glass management of all your Insight Managed devices. 1-Year Insight subscription included

Flexible Mounting
Easy to securely install on the wall of a suspended ceiling with the hardware included

Specification

Product
Product id	786856
Brand	Netgear
Partnr	WAX630-100EUS
EAN/UPC code	606449153965
Warranty (months)	24 months
Management features
Web-based management	Y
Packaging data
Number of products included	1 stuk(s)
Mounting kit	Y
Quick start guide	Y
Features
2.4 GHz	Y
5 GHz	Y
Maximum data transfer rate	6000 Mbit/s
Maximum data transfer rate (2.4 GHz)	1200 Mbit/s
Maximum data transfer rate (5 GHz)	2400 Mbit/s
Ethernet LAN data rates	100, 1000, 2500 Mbit/s
Networking standards	IEEE 802.11ax, IEEE 802.11i, IEEE 802.3af, IEEE 802.3at
Number of users	200 gebruiker(s)
Auto MDI/MDI-X	Y
MIMO	Y
MIMO type	Multi User MIMO
Spread spectrum method	OFDM, OFDMA
Modulation	OFDM
Wi-Fi Multimedia (WMM)/(WME)	Y
VLAN support	Y
Security
Security algorithms	EAP-TLS, PEAP, SSL/TLS, TTLS, WPA, WPA2, WPA3
MAC address filtering	Y
Service Set Identifier (SSID) features	SSID broadcast, SSID broadcast on/off
Auto Wireless Distribution System (WDS)	Y
Remote Authentication Dial-In User Service (RADIUS)	Y
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
DC-in jack	Y
Power
Power over Ethernet (PoE)	Y
Output voltage	12 V
Output current	3.5 A
Design
Placement	Ceiling, Wall
Product colour	White
Reset button	Y
LED indicators	Y
Antenna
Antenna type	Internal
Antenna gain level (max)	4.3 dBi
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Weight & dimensions
Width	266.61 mm
Depth	268.29 mm
Height	55.5 mm
Weight	956 g
