The M4300 Stackable L3 Managed Switch Series comes with 40G, 10G and 1G models in a variety of form factors including PoE+ full provisioning. M4300 Switch Series delivers IPv4/IPv6 rich services for mid-enterprise edge and SMB core with mixed stacking between 40-, 10- and 1-Gigabit models. Layer 3 feature set includes static and policy-based routing, RIP, VRRP, OSPF, and PIM dynamic routing. M4300 is ideal for server aggregation, wireless access, unified communications and Video-over-IP.

Specification

Product
Product id	662900
Brand	Netgear
Partnr	XSM4324FS-100NES
EAN/UPC code	606449142488
Warranty (months)	Limited Lifetime ProSafe Hardware Warranty
Data transmission
MAC address table	16000 entries
Switching capacity	480 Gbit/s
Throughput	357 Mpps
Store-and-forward	Y
Latency (1 Gbps)	2.333 µs
Latency (10 Gbps)	1.323 µs
Number of queues	8
Static route	Y
Number of static routes	64
Jumbo frames support	Y
Jumbo frames	9000
Packet buffer memory	32 MB
Network
Networking standards	IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
10G support	Y
Copper ethernet cabling technology	10GBASE-T
Port mirroring	Y
Policy-based routing	Y
Full duplex	Y
Flow control support	Y
Spanning tree protocol	Y
Broadcast storm control	Y
Link aggregation	Y
Auto-sensing	Y
VLAN support	Y
Virtual LAN features	MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Number of VLANs	4093
Management features
Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Y
Protocols
GARP VLAN Registration Protocol (GVRP)	Y
Routing protocols	OSPF, OSPFv3, RIP, RIP-1, RIP-2
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	2
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
SFP+ module slots quantity	24
Console port	RJ-45/Mini-USB
USB 2.0 ports quantity	1
Security
DHCP features	DHCP client, DHCP relay, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 snooping
Access Control List (ACL)	Y
Access Control List (ACL) rules	64
IGMP snooping	Y
BPDU filtering/protection	Y
Weight & dimensions
Width	212 mm
Depth	345 mm
Height	44 mm
Weight	3560 g
Power
Power supply included	Y
Number of power supply units	1
Power consumption (max)	87.2 W
Optical fiber
Fiber ethernet cabling technology	10GBASE-X
Multicast features
Multicast support	Y
Endurance
Mean time between failures (MTBF)	968447 uur
Design
Rack mounting	Y
Stackable	Y
Form factor	1U
Product colour	Black, Grey
Airflow direction	Front-to-back airflow
Operational conditions
Heat dissipation	330.6 BTU/h
Performance
Physical stacking (units)	8
Built-in processor	Y
Processor frequency	800 MHz
Internal memory	1024 MB
Flash memory	256 MB
Noise level	39.7 dB
Power over Ethernet (PoE)
Power over Ethernet (PoE)	N
