The Neomounts by Newstar WL35-350BL12 is a tiltable wall mount for flat screens up to 55" with a maximum weight capacity of 25 kg. The versatile tilt technology (14°), allows you to create the optimum viewing angle.

The WL30-350BL12 has a depth of 4, 6 cm and is suitable for screens that meet VESA hole pattern 50x50 to 200x200 mm. It is possible to lock the individual brackets of the mount using a padlock (not included).

A practical bolt bag is included in the packaging, for quick and easy installation.

Specification

Product
Product id	859116
Brand	Neomounts
Partnr	WL35-350BL12
EAN/UPC code	8717371449636
Warranty (months)	5 year
Mounting
Maximum weight capacity	25 kg
Minimum screen size compatibility	24 "
Maximum screen size	55
Mounting type	Wall
Suitable for TV	Y
Minimum VESA mount	50 x 50 mm
Maximum VESA mount	200 x 200 mm
Panel mounting interface	50 x 50, 75 x 75, 75 x 100, 75 x 200, 100 x 100, 100 x 150, 100 x 200, 100 x 75, 120 x 120, 200 x 100, 200 x 200 mm
Number of displays supported	1
Distance to the wall (max)	46 mm
Ergonomics
Tilt angle range	-2 - 10 °
Cable management	N
Tilt adjustment	Y
Design
Product colour	Black
Housing material	Steel
Accepts padlock	Y
Technical details
Warranty period	5 jaar
Weight & dimensions
Width	250 mm
Depth	46 mm
Height	225 mm
Weight	650 g
Package width	63 mm
Package depth	55 mm
Package height	360 mm
Package weight	1000 g
Package net weight	1000 g
Logistics data
Master (outer) case width	236 mm
Master (outer) case length	210 mm
Master (outer) case height	380 mm
Master (outer) case weight	11700 g
Quantity per master (outer) case	12 stuk(s)
Master (outer) case net weight	7800 g
Harmonized System (HS) code	7326 90 98 90
Quantity per EUR-pallet	720 stuk(s)
Other features
Country of origin	China
