The ProDVX APPC-10SFN is a versatile 10.1” Android Panel PC featuring a Full Surround LED bar and
an integrated NFC reader, making it perfect for dynamic environments and interactive applications.
Powered by the RockChip RK3568 Quad-core processor and running Android 13, it delivers reliable
performance with 4GB RAM and 16GB storage, expandable via SD card. The customizable Full
Surround LED bar enhances branding or provides visual status indicators, while the NFC reader (NXP
PN7160) enables seamless contactless interactions, ideal for retail, hospitality, and access control.
Its direct-bonded IPS touchscreen with 1280x800 resolution oers sharp visuals and responsive
touch, complemented by PoE+, fanless cooling, mini-HDMI out, and versatile connectivity options
(USB, LAN). Designed for 24/7 operation with a demonstrated MTBF of 50, 000 hours, this compact
yet durable device supports flexible mounting options to meet diverse business needs.

Specification

Product
Product id	986380
Brand	ProDVX
Partnr	5010730
EAN/UPC code
Warranty (months)	3 years
Display
Display diagonal	10.1 inch
Display resolution	1280 x 800 Pixels
Touchscreen	Y
HD type	HD
LED backlight	Y
Touch technology	Multi-touch
Native aspect ratio	16:10
Display brightness	450 cd/m²
Panel type	IPS
Anti-glare screen	Y
Contrast ratio (typical)	1000:1
Viewing angle, vertical	160 °
Viewing angle, horizontal	160 °
Processor
Processor manufacturer	Rockchip
Processor family	Rockchip
Processor model	RK3568
Processor frequency	2 GHz
Processor cores	4
Memory
Internal memory	8 GB
Internal memory type	LPDDR4-SDRAM
Maximum internal memory	8 GB
Neural processor unit (NPU)
Neural processor unit (NPU)	RockChip NPU
AI datatype support on NPU	BFP16, FP16, INT16, Int8
AI software frameworks supported by NPU	Android NN, Caffe, Onnx, Pytorch, TensorFlow, Tflite
NPU performance up to	1 TOPs
Storage
Total storage capacity	16 GB
Storage media	eMMC
Optical drive type	N
Card reader integrated	Y
Compatible memory cards	SD
Graphics
Discrete graphics adapter	N
Discrete graphics adapter model	Not available
On-board graphics adapter	Y
On-board graphics adapter family	ARM Mali
On-board GPU manufacturer	ARM
On-board graphics adapter model	ARM Mali-G52 2EE MC2
Audio
Built-in speaker(s)	Y
Number of speakers	2
RMS rated power	3 W
Built-in microphone	Y
Audio formats supported	AAC, ASF, MP2, OGG, WAV, WMA
Camera
Built-in camera	N
Network
Wi-Fi	N
Ethernet LAN	Y
Wi-Fi ready	Y
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Bluetooth	N
Ports & interfaces
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
HDMI ports quantity	1
Audio output	Y
DC-in jack	Y
Design
Product colour	Black
Wall mountable	Y
Housing material	Plastic
VESA mounting	Y
Panel mounting interface	75 x 75 mm
Performance
Product type	All-in-One PC
Software
Operating system installed	Android 13
Brand-specific features
Brand specific technologies	AI-Q Engine, ClearFrame Design, FusionTouch Technology, ProSecure, SLB-Lumi Technology
Power
AC adapter output voltage	12 V
Power consumption (typical)	23 W
Weight & dimensions
Width (without stand)	240.9 mm
Depth (without stand)	159.7 mm
Height (without stand)	24.4 mm
Weight (without stand)	600 g
Weight	600 g
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 procent
Storage relative humidity (H-H)	10 - 90 procent
Certificates
Compliance certificates	Federal Communications Commission (FCC), CE, RoHS, REACH, UKCA
Other features
AC adapter output current	2 A
Mean time between failures (MTBF)	50000 uur
Video formats supported	H.264, MP4, MPEG2, MPEG4, MPG
Near Field Communication (NFC)	Y
Backlight type	Edge LED
Mini HDMI ports quantity	1
Battery type	CR1220 Lithium metal, non rechargeable
