TS-h765eU
Compact 1U short-depth rackmount NAS, with E1. S/M.2 PCIe NVMe slots and 10GbE expandability

The 1U short-depth rackmount TS-h765eU is designed for space-constrained environments, offering an efficient and reliable storage solution for various needs. Adopting the latest Intel® Atom x7000C Series processor, the TS-h765eU comes with four 3.5-inch drive bays and three E1. S / M.2 PCIe NVMe slots for exceptional expandability, making it an ideal NAS for high performance and multitasking demands. The TS-h765eU runs the ZFS-based QuTS hero operating system that ensures data integrity and WORM protection for data immutability.

Specification

Product
Product id	979776
Brand	QNAP
Partnr	TS-H765EU-8G
EAN/UPC code	4711103085721
Warranty (months)	3-year
Storage
Storage drives installed	N
Number of storage drives supported	4
Installed storage drive type	N
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	Serial ATA II, Serial ATA III
Storage drive sizes supported	3.5, E1. S "
RAID support	Y
RAID levels	0, 1, 5, 6, 10, 50, JBOD
Online RAID migration	Y
Online RAID expansion	Y
RAID rebuild	Y
Hot-swap drive bays	Y
Supported file systems	FAT32, HFS+, NTFS, exFAT, ext3, ext4
Bad block scan	Y
Disk roaming	Y
Auto-rebuild	Y
Processor
Processor manufacturer	Intel
Processor family	Intel Atom
Processor boost frequency	3.4 GHz
Processor cores	4
Number of processors supported	1
Memory
Internal memory type	DDR5
Internal memory	8 GB
Maximum RAM supported	16 GB
Memory form factor	SO-DIMM
Memory slots	1
Flash memory	8000 MB
Network
Ethernet LAN	Y
Ethernet LAN data rates	100, 1000, 2500 Mbit/s
DHCP server	Y
iSCSI support	Y
Dynamic DNS (DDNS)	Y
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
USB port	Y
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Concurrent connections	1500
Design
Chassis type	Rack (1U)
Cooling type	Active
Product colour	Black, Grey
Number of fans	3 ventilator(en)
Fan diameter	40 mm
LED indicators	Y
Performance
Type	NAS
Device class	Small & Medium Business
Backup function	Y
Buzzer	Y
Snapshot	Y
Disk scan	Y
Remotely operated	Y
S. M. A. R. T. support	Y
Password authentication	Y
Reset button	Y
On/off switch	Y
Browser supported	Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
Software
Operating system installed	QuTS hero
Operating system version	h5.2.3
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8
Linux operating systems supported	Y
Mac operating systems supported	Y
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022
Other operating systems supported	IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 11
Power
Power supply location	Built-in
Power supply unit (PSU) capacity	150 W
Number of power supply units	1
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Weight & dimensions
Width	430 mm
Depth	292.1 mm
Height	43 mm
Weight	4510 g
Packaging content
Cables included	AC
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 procent
Storage temperature (T-T)	20 - 70 °C
