Samsung Galaxy Book5 NP750XHDA-EXP. Product type: Laptop, Form factor: Clamshell. Processor family: Intel Core Ultra 5, Processor model: 225U. Display diagonal: 39.6 cm (15.6"), HD type: Full HD, Display resolution: 1920 x 1080 pixels. Internal memory: 16 GB, Internal memory type: LPDDR5x-SDRAM. Total storage capacity: 512 GB, Storage media: SSD. On-board graphics card model: Intel® Graphics. Operating system installed: Windows 11 Home. Product colour: Silver. Weight: 1.55 kg

Specification

Product
Product id	1013501
Brand	Samsung
Partnr	NP750XHD-KB4NL
EAN/UPC code	8806097622017
Design
Product type	Notebook
Product colour	Silver
Form factor	Clamshell
Display
Display diagonal	15.6 inch
Display resolution	1920 x 1080 Pixels
Touchscreen	N
Panel type	IPS
HD type	Full HD
Display brightness	330 cd/m²
Maximum display brightness (HDR)	500 cd/m²
Maximum refresh rate	60 Hz
Processor
Processor manufacturer	Intel
Processor family	Intel Core Ultra 5
Processor model	225U
Processor generation	Intel Core Ultra (Series 2)
Processor boost frequency	4.8 GHz
Processor cores	12
Processor threads	14
Low Power Efficient-cores	2
Efficient-core base frequency	1.3 GHz
Efficient-core Max Turbo Frequency	3.8 GHz
Low Power Efficient-core Max Turbo Frequency	2.4 GHz
Processor cache	12 MB
Performance-core base frequency	1.5 GHz
Performance-core Max Turbo Frequency	4.8 GHz
Low Power Efficient-core Base Frequency	700 MHz
Processor cache type	Smart Cache
Processor socket	FCBGA2049
Processor base power	15 W
Maximum turbo power	57 W
Performance cores	2
Efficient cores	8
Memory
Internal memory	16 GB
Internal memory type	LPDDR5x-SDRAM
Memory form factor	On-board
Maximum internal memory	16 GB
Neural processor unit (NPU)
Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Y
Windows Studio effects support	Y
AI software frameworks supported by NPU	ONNX RT, OpenVINO, Windows ML
NPU performance up to	12 TOPs
Storage
Total storage capacity	512 GB
Storage media	SSD
Total SSDs capacity	512 GB
Number of SSDs installed	1
SSD capacity	512 GB
SSD interface	PCI Express 4.0
NVMe	Y
SSD form factor	M.2
Optical drive type	N
Card reader integrated	Y
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Graphics
On-board graphics adapter	Y
Discrete graphics adapter	N
Discrete graphics adapter model	Not available
On-board graphics adapter model	Intel Graphics
On-board graphics adapter DirectX version	12.2
On-board graphics adapter OpenGL version	4.6
Audio
Number of built-in speakers	2
Speaker power	2 W
Built-in microphone	Y
Number of microphones	2
Camera
Front camera	Y
Network
Bluetooth	Y
Mobile network connection	N
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Antenna type	2x2
Ethernet LAN	Y
Bluetooth version	5.2
Ports & interfaces
USB 3.2 Gen 2x2 Type-C ports quantity	2
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
Intel® Thunderbolt 4	Y
Combo headphone/mic port	Y
Keyboard
Pointing device	Touchpad
Numeric keypad	Y
Copilot key	Y
Software
Operating system installed	Windows 11 Home
Battery
Battery technology	Lithium-Ion (Li-Ion)
Number of battery cells	4
Battery voltage	15.52 V
Battery capacity (Watt-hours)	61.2 Wh
Battery capacity	3802 mAh
Battery life (max)	19 uur
Battery recharge time	1.8 uur
Power
AC adapter power	45 W
USB Type-C charging port	Y
Security
Cable lock slot	Y
Cable lock slot type	Kensington
Trusted Platform Module (TPM)	Y
Trusted Platform Module (TPM) version	2.0
Weight & dimensions
Weight	1550 g
Width	356.6 mm
Depth	228 mm
Height	15.1 mm
Technical details
Repairability index	8.7
