The Shuttle XPC slim Barebone XB860G2 is a 4.5-litre PC with two slots for PCI-Express expansion cards. Together with a powerful socket LGA1851 Intel Core Ultra 2xx desktop processor (code name "Arrow Lake-S"), this platform is perfectly suited for many professional applications where performance, flexibility and a compact form factor matter. You can install e. g. a multiport graphics card, a video capture card or I/O card to set up a mini PC for applications such as video wall presentations, graphics workstations, media capturing, surveillance, POS, POI as well as network and industrial applications. Even mid-range gaming is possible.

Specification

Product
Product id	1020932
Brand	Shuttle
Partnr	SHU-XB860G2
EAN/UPC code	887993008134
Processor
Built-in processor	N
Memory
Memory slots type	SO-DIMM
Internal memory installed	N
Number of memory slots	2
Memory channels	Dual-channel
Memory voltage	1.1 V
Supported memory clock speeds	5600 MHz
Supported memory types	DDR5-SDRAM
Maximum internal memory	96 GB
Non-ECC	Y
Storage
Storage drives installed	N
Supported storage drive types	SSD
Storage drive sizes supported	M.2 "
SSD form factor	M.2
Storage drive interface	PCI Express
Number of storage drives supported	3
NVMe	Y
Graphics
On-board graphics adapter	Y
Audio
Built-in speaker(s)	N
Network
Ethernet LAN	Y
Wi-Fi	N
LAN controller	Intel I226-LM, Intel I219-LM
Ports & interfaces
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
HDMI ports quantity	2
HDMI version	2.0/2.1
DisplayPorts quantity	1
DisplayPort version	1.4a
Microphone in	Y
Headphone outputs	1
Ethernet LAN (RJ-45) ports	2
DC-in jack	Y
Design
Chassis type	3.5L sized PC
Product colour	Black
Cooling type	Active
LED indicators	HDD, Power
Cable lock slot	Y
Cable lock slot type	Kensington
VESA mounting	Y
Panel mounting interface	75 x 75, 100 x 100 mm
Product type	PC barebone
Performance
Motherboard form factor	Mini ITX
Motherboard chipset	Intel B860
Processor socket	LGA 1851 (Socket V1)
Number of processors supported	1
BIOS type	UEFI AMI
Trusted Platform Module (TPM)	Y
Trusted Platform Module (TPM) version	2.0
Audio chip	Realtek ALC888S
Harmonized System (HS) code	84733080
Technical details
Sustainability certificates	ErP, ENERGY STAR
Compliance certificates	UKCA, CE, Federal Communications Commission (FCC), BSMI, RCM, VCCI, RoHS
Power
Power supply type	External AC adapter
Power supply	180 W
Number of power supply units	1
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
AC adapter output voltage	19.5 V
AC adapter output current	9.23 A
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 procent
Weight & dimensions
Width	238 mm
Depth	200 mm
Height	72.5 mm
Weight	1900 g
Package weight	3200 g
Packaging content
Power cord included	Y
AC adapter included	Y
Quick start guide	Y
Drivers included	Y
