Remotely capture broadcast quality Full HD images with smooth, silent PTZ and excellent low-light sensitivity.

The BRC-H800 remote camera combines uncompromising broadcast picture quality and smooth, silent PTZ operation with the flexibility of 3G-SDI and HDMI connections.
Designed for unattended operation, this compact but powerful robotic camera is an ideal complement to other broadcast cameras for capturing images in hard-to-reach or unobtrusive positions. It's equally at home in TV newsrooms, remote studios and on-air suites, auditoriums, houses of worship, courtrooms or sports stadiums. It's also particularly suited to efficient multi-camera set-ups, under the control of a single operator.
The 1-inch type Exmor R CMOS image sensor captures crisp, low-noise Full HD images at 60p, with excellent low-light sensitivity. The large image sensor also allows the creation of beautiful 'bokeh' effects with a shallow depth of field to suit any artistic intention.
Speedy, near-silent PTZ operation with 12x optical zoom accommodates wide-angle scenes and tightly framed close-ups, with Clear Image Zoom 24x(HD) extending this range even further without visible loss of resolution. Broadcast-friendly features include dual tally lamps for on-air operation, while operational flexibility is enhanced with options for ceiling, table top or tripod mounting. There’s also a broad range of video interfacing and remote control possibilities - plus support for PoE+ and genlock - for smooth integration into any broadcast, professional or corporate AV environment.

Enhanced Pan/Tilt/Zoom (PTZ) operation
Accurately re-frame shots or track moving subjects with smooth, speedy, near-silent remote control of pan, tilt and zoom functions. There's also low-speed zoom and a slow pan/tilt mode for precise, judder-free camera movements. PTZ Trace Memory allows a sequence of camera movements to be memorised and followed whenever required. PTZ Motion Sync smoothly blends separate pan, tilt and zoom movements for seamless, professional-looking transitions. Upto 100 preset positions for pan/tilt/zoom operations.

Broadcast quality Full HD 60p images
The camera's large, back-illuminated 1.0-type Exmor R CMOS sensor delivers uncompromised broadcast quality colour pictures in detail-packed Full HD 60p, capable of capturing sports and other fast-moving action.

Cinematic 24p pictures
The camera can also operate in 24p mode, for video footage with a rich, filmic look.

High quality 12x optical zoom and 24x(HD) with Clear Image Zoom
The high quality Zeiss Vario-Sonnar T lens with 12x optical zoom range covers wide angle shots as well as tight close-ups. Clear Image Zoom* expands this range to 24x (HD) without sacrificing detail. In addition, the Tele Convert Mode can double this range again, up to 48x zoom while maintaining a 1920x1080 resolution.

Excellent low light sensitivity
The BRC-H800 can capture crisp, low noise colour video images in light levels as low as 1.7lx, making it an ideal choice for dimly lit live hall and theater

Flexible installation
Integration is simplified in a wide range of environments, with PoE+ (Power over Ethernet) to reduce cabling requirements and VISCA control over IP.

Remote operation
Pan/tilt/zoom and other camera settings can be controlled using the supplied IR remote commander, or with the optional RM-IP500 Remote Control Unit that can control multiple cameras.

RCP/MSU Connectivity
In an studio environment, BRC-H800 can be controlled via Sony’s Remote Control Panel RCP-1500/1501/1530 and MSU-1000/1500. Connection can be made over IP networks.

Genlock
Genlock simplifies integration with other systems in multi-camera broadcast environments.

Versatile video outputs
Enjoy greater installation flexibility in professional broadcast and AV environments with 3G-SDI (x2) and HDMI video outputs.

Front and rear tally lamps
Ideal for on-air broadcast use, the BRC-H800 features dual tally lamps on the front and rear of the camera body. Brightness of the front tally lamp can be adjusted in two steps.

Always up to date
New camera functionality and performance improvements can be added via firmware updates over IP

Simplified construction of VR/AR systems
Real-time camera tracking data (pan/tilt/zoom/focus/iris) can be output from the camera over IP network in free-d* protocol. It can construct VR/AR system without additional tracking system, easy and cost effective solution.

Specification

Product
Product id	973016
Brand	Sony
Partnr	BRC-H800/W
EAN/UPC code	5013493411777
Performance
Type	IP security camera
Placement supported	Indoor
PTZ control	Y
Preset points	Y
Day/night mode	Y
Light exposure modes	Aperture priority AE, Auto, Manual
Design
Form factor	Dome
Mounting type	Ceiling/Floor
Product colour	White
Camera
Camera pan control	Y
Camera tilt control	Y
Minimum illumination	1.7 Lux
Lens viewing angle, horizontal	64.6 °
Tilt angle range	-30 - 90 °
Tilt speed	60 °/sec
Pan range	-170 - 170 °
Pan speed	60 °/sec
White balance	Auto, Indoor, Manual, One push, Outdoor
Camera shutter speed	1/10000s to 1/8 s
Image sensor
Sensor type	CMOS
Lens system
Optical zoom	12 x
Focus	Motorized/Manual
Focal length range	9.3 - 111.6 mm
Video
Maximum resolution	1920 x 1080 Pixels
Total megapixels	20.4 MP
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Gain control type	Auto/Manual
Flip & mirror	Y
Network
Ethernet LAN	Y
Networking standards	IEEE 802.1Qaz
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
RS-422 ports	1
HDMI ports quantity	2
Management features
Remotely operated	Y
Power
Power source type	PoE
Power consumption (typical)	19 W
Power consumption (Power over Ethernet (PoE))	23 W
Power over Ethernet (PoE)	Y
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Weight & dimensions
Width	198 mm
Depth	260 mm
Height	238 mm
Weight	4300 g
Packaging content
Number of cameras	1
Mounting kit	Y
Screws included	Y
