Connect a DisplayPort Alt Mode-enabled USB-C source to a DisplayPort monitor with support for resolutions up to 8K at 60HzConnect an 8K 60Hz or 4K 144Hz DisplayPort monitor to a DP Alt Mode-enabled USB Type-C source up to 9.8ft (3m) away with this USB-C to DisplayPort adapter cable. High-Resolution HDR VideoThis USB-C to DisplayPort Cable enables resolutions of up to 8K 60Hz and is DisplayPort 1.4 compliant. It supports HDR10, DSC, and 2 channel audio. Hardware PlatformSingle MonitorDisplayPort Alt ModeIntel 11th Gen & Later Processors8K 60Hz or 4K 144Hz*DisplayPort 1.4Nvidia RTX3000 and AMD RX6000 or later8K 60Hz or 4K 144HzDisplayPort 1.4Intel 10th Gen & Earlier4K 60HzDisplayPort 1.4Apple M1/M2/M3 + Pro & Max4K 60Hz**DisplayPort 1.4*DSC support required to reach maximum resolution capabilities on Intel 11th Gen or later**Apple MacBook's with M1/M2/M3 Pro/Max silicon do not support 8K 60Hz over USB-C DP Alt ModeUniversal CompatibilityThe USB-C to DisplayPort Converter Cable is compatible with laptops and devices from various brands such as Dell, HP, Lenovo, Microsoft, and more. It works with all hardware platforms and any operating system. The USB Type-C to DisplayPort Cable requires no drivers or software and works with USB-C DP Alt Mode, USB4, Thunderbolt 3, and Thunderbolt 4 laptops and devices. Thoughtfully DesignedCombining a video adapter and cable minimizes potential points of failure and signal loss. A latching DisplayPort connector reduces the risk of accidental disconnections. The cable is equipped with aluminum connector shells, providing enhanced durability, and shielding from Electromagnetic Interference (EMI). The StarTech. com Advantage

Specification

Product
Product id	966999
Brand	StarTech.com
Partnr	142-USBC-DP-8K-10F
EAN/UPC code	065030901291
Warranty (months)	3 Years
Features
Cable length	3 m
Connector 1	USB Type-C
Connector 2	DisplayPort
Connector 1 gender	Male connector
Connector 2 gender	Male connector
Connector 1 form factor	Straight
Connector 2 form factor	Straight
HDCP	Y
HDCP version	1.4/2.2/2.3
DisplayPort version	1.4
USB Type-C DisplayPort Alternate Mode	Y
High Dynamic Range (HDR) supported	Y
Supported graphics resolutions	800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768, 1280 x 768 (WXGA), 1280 x 800, 1280 x 800 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 2560 x 1080, 3440 x 1440, 3840 x 2160, 4096 x 2160, 5120 x 1440, 5120 x 2880, 7680 x 4320
Maximum refresh rate	144 Hz
Bandwidth	32400 MB/s
Refresh rate at maximum resolution	60 Hz
Product colour	Black, Grey
Chipset	VL103
Jacket material	Thermoplastic Elastomer (TPE)
Plug and Play	Y
Cable type	Round cable
Latching connectors	Y
Operational conditions
Operating temperature (T-T)	-20 - 70 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 procent
Sustainability
Sustainability compliance	Y
Packaging data
Package width	150 mm
Package depth	100 mm
Package height	100 mm
Package weight	80 g
Technical details
Sustainability certificates	RoHS
Compliance certificates	RoHS
Weight & dimensions
Cable diameter	4.3 mm
Weight	111 g
Logistics data
Master (outer) case width	300 mm
Master (outer) case length	300 mm
Master (outer) case height	350 mm
Quantity per master (outer) case	100 stuk(s)
