Extend a 4K 60Hz HDMI signal over CAT6/6A cabling for distances of up to 200ft (60m) with Power over Cable

The HDMI Extender is designed to transmit visually lossless and low latency 4K 60Hz video and 7.1 channel audio up to 200 feet (60 meters) over a single network cable.

4K 60Hz Resolution

This HDMI over CAT5e extender is HDMI 2.0 compliant and supports up to 4K 60Hz resolutions, HDR, HDCP 2.2, DTS, and Dolby Digital audio. This makes it suitable for high-quality video and audio transmission over long distances.

Power-Over-Cable

The extender features Power-over-Cable (PoC) technology, allowing the included power adapter to connect only to the transmitter while providing power to both the transmitter and receiver through the CAT5e/6 cable. This feature reduces the need for additional power sources at the receiver end.

Versatile Installation Options

A point-to-point connection uses a single CAT6/5e cable and requires no drivers, software, or IP configuration, significantly reducing setup time. The HDMI extender can be mounted on a wall, ceiling, or the underside of a table using the included brackets, offering versatile professional installation options. The HDMI extender offers a longer range than HDMI cables, and Ethernet cables are easier to run in walls, behind furniture, or through cable trays. Its compact form factor makes it ideal for boardrooms, digital signage, trade shows, and classrooms.

The StarTech. com Advantage

Specification

Product
Product id	987253
Brand	StarTech.com
Partnr	4K50IC-EXTEND-HDMI
EAN/UPC code	065030918299
Warranty (months)	2 Years
Features
Type	AV transmitter & receiver
Maximum resolution	3840 x 2160 Pixels
Cable types supported	Cat5e, Cat6
Maximum transfer distance	60 m
Maximum refresh rate	60 Hz
Audio output channels	7.1 kanalen
Rack mounting	N
HDCP version	2.2
Supported graphics resolutions	800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1280 x 960, 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1440 x 900, 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 1920 x 1440, 2048 x 1152, 2048 x 1536 (QXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 2560 x 1920, 2560 x 2048
HDCP	Y
Material	Metal
Product colour	Black
Ports & interfaces
Connectivity technology	Wired
RJ-45 input ports	1
RJ-45 output ports	1
HDMI version	2.0
Number of HDMI outputs	1
HDMI in	1
USB ports quantity	1
USB connector type	USB Type-C
Power
Power source type	USB
AC input voltage	100 - 240 V
Operating voltage (transmitter)	5 V
Input current	0.3 A
Output current	2 A
Operating voltage (receiver)	5 V
Power consumption (typical)	10 W
USB Power Delivery	Y
External power adapter	Y
Operational conditions
Operating temperature (T-T)	-20 - 60 °C
Storage temperature (T-T)	-30 - 70 °C
Operating relative humidity (H-H)	0 - 90 procent
Weight & dimensions
Receiver dimensions (W x D x H)	40 x 67 x 23 mm
Receiver weight	92 g
Transmitter dimensions (WxDxH)	40 x 67 x 23 mm
Transmitter weight	92 g
Packaging data
Package width	150 mm
Package depth	117 mm
Package height	77 mm
Package weight	364 g
Packaging content
AC adapter included	Y
Included power plug types	ANZ, EU, NA, UK
Quick start guide	Y
Mounting brackets included	Y
Technical details
Compliance certificates	Federal Communications Commission (FCC), RoHS
Logistics data
Master (outer) case width	430 mm
Master (outer) case length	330 mm
Master (outer) case height	380 mm
Quantity per master (outer) case	30 stuk(s)
