Connect multiple 5Gbps USB-A peripherals that draw high power to your computer using a single USB-A port.

This USB Hub adds four USB-A 3.2 Gen 1 (5Gbps) ports to a USB-A enabled desktop or laptop computer. The USB Hub connects to a USB-A port on a computer, using the built-in 1ft. (30cm) host cable. The USB hub is backward compatible with USB 2.0 (480Mbps) devices, ensuring support for a wide range of modern and legacy USB peripherals (e. g. , thumb drives, external HDDs/SSDs, HD cameras, mice, keyboards, webcams, and audio headsets). The USB hub is compact in size, facilitating portability when travelling.

Bus-Powered with Optional Auxiliary Power

The USB hub can operate with bus power alone. It features a USB Type-C power input that can be connected to a USB-C power adapter (sold separately), providing up to 15W (5V/3A) of power in addition to the bus power from the host. This flexibility is ideal for applications requiring additional power, such as connecting a high-power USB device (e. g. , external HDD/SSD), while using the other ports to connect lower powered devices. The downstream ports are each capable of providing up to 7.5W of power to the connected peripherals. For added protection to connected USB devices, the USB ports feature Overcurrent Protection (OCP). OCP prevents USB peripherals from drawing more power than is safely allocated for each port.

Plug and Play

This device is OS independent, supporting all operating systems, including Windows, macOS, and ChromeOS. The Hub is automatically detected, configured, and installed upon connection to a host computer. The built-in extra-long 1 ft. (30 cm) USB-A host cable ensures easy setup and reduces connector strain on devices such as the Surface Pro, HP Elite X2, Lenovo X1 Carbon, Dell XPS, and laptops on riser stands.

Enterprise Management Tools

StarTech. com Connectivity Tools offer practical utilities to support device management and increase productivity in modern IT environments. The applicable software for this product is the USB Event Monitoring Utility which allows administrators to track and log connected USB devices.

Visit StarTech. com/Connectivity-Tools to download the Enterprise Management Tools.

Specification

Product
Product id	1002086
Brand	StarTech.com
Partnr	5G4AC-USB-A-HUB
EAN/UPC code	065030906227
Warranty (months)	2 Years
Ports & interfaces
Ports quantity	5
Host interface	USB 3.2 Gen 1 (3.1 Gen 1) Type-A
Hub interfaces	USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 2.0 Type-C ports quantity	1
Features
Data transfer rate	5000 Mbit/s
Housing material	Plastic
Product colour	Grey
Overcurrent protection	Y
Cable length	0.3 m
Plug and Play	Y
Network
UASP support	Y
Power
Power supply type	USB
Technical details
Compliance certificates	CE, RoHS
System requirements
Windows operating systems supported	Y
Mac operating systems supported	Y
Linux operating systems supported	Y
Other operating systems supported	ChromeOS
Weight & dimensions
Width	54 mm
Depth	420 mm
Height	16 mm
Weight	82 g
Packaging data
Package width	120 mm
Package depth	160 mm
Package height	30 mm
Package weight	145 g
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	10 - 85 procent
Performance
Mean time between failures (MTBF)	302079 uur
Logistics data
Master (outer) case width	13 mm
Master (outer) case length	473 mm
Master (outer) case height	440 mm
Quantity per master (outer) case	80 stuk(s)
Other features
Chipset	VIA - VL817
