Convert and extend a Gigabit RJ45 Ethernet connection over single or multimode LC fiber

This compact Gigabit Fiber to Ethernet Media Converter enables Cat6 or similar cabling to be upgraded to an EMI-free fiber connection. The TAA-compliant adapter is PoE powered by, making it a perfect choice when external power options are unavailable.

Simplified Installation

The unmanaged fiber media converter features a plug-and-play design that does not require additional software or settings to be changed. The metal housing features an IP20 rating and is an all-in-one construction with integrated LC fiber and RJ45 ports. The RJ45 side features a metal tab to ensure a reliable and secure fit and prevent accidental disconnections.

Network Features

The PoE media converter is designed to work seamlessly with any networking equipment that is PoE-capable and supports the 802.3af standard or higher. It comes equipped with a range of PoE protection features, including Over Voltage Protection (OVP), Over Current Protection (OCP), Over Temperature Protection (OTP), and 2KV Surge Protection. The LC slot is compatible with Single-Mode (10km) and Multimode (800m) fiber cables up to 1Gbps. A spring-loaded tab protects the port when not in use. The converter supports LFPT (Link Fault Pass-Through), allowing IT administrators to monitor and assess network connectivity at a glance based on the LED behavior.

Compatibility

This LAN-to-fiber converter is ideal for upgrading computers, switches, routers, or other equipment from copper to fiber. It suits various applications, including field deployments, industrial automation, telecommunications, broadcasting, data centers, and remote networking. Experience reliable connectivity with EMI immunity over long distances with this compact (3.2×0.8×0.7in/82.39x20x17.5mm) and power-efficient (2.5W max) dongle.

The StarTech. com Advantage

Specification

Product
Product id	970574
Brand	StarTech.com
Partnr	D01ML55P-FIBER-MEDIA
EAN/UPC code	065030909822
Warranty (months)	2-Year Warranty
Technical details
Compliance certificates	Trade Agreements Act (TAA)
Network
Maximum data transfer rate	1000 Mbit/s
Converter input interface	1000Base-T
Converter output interface	1000Base-LX
Networking standards	IEEE 802.3ab, IEEE 802.3af, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-T
Fiber ethernet cabling technology	1000BASE-LX
Auto MDI/MDI-X	Y
Auto-negotiation	Y
Chipset	Marvell - 88E1512
Ports & interfaces
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Fiber ports quantity	1
Fiber optic connector	LC
Performance
Maximum transfer distance	10000 m
Wavelength	1310 nm
Fiber mode structure	Multi-mode, Single-mode
Design
Internal	N
International Protection (IP) code	IP20
Housing material	Metal
Product colour	Silver
LED indicators	Activity, Link, Power
Power
Power consumption (typical)	2.5 W
Power over Ethernet (PoE)	Y
Packaging data
Package width	136 mm
Package depth	80 mm
Package height	32 mm
Package weight	75 g
Weight & dimensions
Width	82 mm
Depth	20 mm
Height	17 mm
Weight	42 g
Operational conditions
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	5 - 85 procent
Packaging content
Quick installation guide	Y
Logistics data
Master (outer) case width	340 mm
Master (outer) case length	290 mm
Master (outer) case height	126 mm
Quantity per master (outer) case	24 stuk(s)
