Enable reliable 8K 60Hz video using this DisplayPort 1.4 Cable

This DisplayPort 1.4 cable connects your DisplayPort™ laptop or desktop computer to an ultra-high definition 8K monitor, TV or projector. It supports resolutions up to 8K (7680 x 4320) at 60Hz.

The DisplayPort monitor cable provides the essential connection to support the next generation of ultra-high definition video.

Full-Featured DisplayPort 1.4

This 8K DisplayPort cable supports all DP 1.4 features:

• High Bit Rate 3 (HBR3) Bandwidths of 32.4 Gbps supporting the latest in industry standards
• High Dynamic Range (HDR10) for higher contrast ratio and vivid colors
• Multi-Stream Transport (MST) for daisy-chaining multiple monitors
• Display Stream Compression 1.2 (DSC) for maximum resolution output
• Forward Error Correction to manage data transmission errors
• High-Bandwidth Digital Content Protection (HDCP 2.2) for a secure connection between source and display
• 32 Uncompressed Digital Audio Channels

Cable Key Features

Aluminum-mylar foil with braided shielding improve EMI protection

Long lasting flexible TPE jacket & strain relief (TPE is non-toxic & halogen free for environmental sustainability)

Connector Key Features

Die-cast aluminium sub-structure shielding improves signal integrity & prevents signal degradation

Corrosion-free gold-plated connectors ensure premium video quality & enhanced reliability

Tested to withstand 5000+ insertions

8K: Enabling Business Continuity

8K has a resolution of 7680 x 4320 and is also known as 4320p and Ultra High Definition (UHD). Suitable for digital signage and other commercial displays that require the highest available resolution. This cable is backward compatible with 4K and 5K displays making it the perfect peripheral to start futureproofing your cabling infrastructure.

Comprehensive Product Testing & Expert Technical Support

StarTech. com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to our customers. Our local StarTech. com Technical Advisors have a broad product expertise and work directly with StarTech. com Engineers to provide support for our customers both pre and post-sales.

DP14VMMV1M is backed by a StarTech. com lifetime warranty.

The StarTech. com Advantage

Specification

Product
Product id	970571
Brand	StarTech.com
Partnr	DP14VMM1F
EAN/UPC code	065030909792
Warranty (months)	Lifetime
Features
Cable length	0.3 m
Connector 1	DisplayPort
Connector 2	DisplayPort
Connector 1 gender	Male connector
Connector 2 gender	Male connector
Connector 1 form factor	Straight
Connector 2 form factor	Straight
Connector contacts plating	Gold
DisplayPort version	1.4
Maximum resolution	7680 x 4320 Pixels
Supported graphics resolutions	3840 x 2160, 7680 x 4320
Maximum refresh rate	120 Hz
HDCP	Y
HDCP version	2.2
Display Stream Compression (DSC)	Y
Latching connectors	Y
Display Stream Compression (DSC) version	1.2
Product colour	Black, Grey
Cable shielding	Aluminum mylar foil
Jacket material	Thermoplastic Elastomer (TPE)
AWG wire size	34
High Dynamic Range (HDR) supported	Y
Bandwidth	32400 MB/s
Multi-Stream Transport (MST)	Y
HBR3 support	Y
Number of conductors	19
Channels quantity	32 kanalen
Colour sampling	4:4:4
Packaging data
Cable diameter	4.5 mm
Package width	220 mm
Package depth	200 mm
Package height	20 mm
Package weight	18.5 g
Logistics data
Master (outer) case width	400 mm
Master (outer) case length	330 mm
Master (outer) case height	270 mm
Quantity per master (outer) case	150 stuk(s)
Technical details
Compliance certificates	RoHS
