Add a second power supply to your media chassis to connect a redundant power supply for uninterrupted operation.

Continuous, Reliable Power

The redundant power supply unit delivers 130W AC to maintain uninterrupted operation across all fifteen media converter slots. It is ideal for enterprise, ISP, and metro networks where continuous uptime and stable performance are essential.

Hot-Swappable Redundancy

The unit installs easily into the redundant power bay of the MCM15-MEDIA-CHASSIS, providing automatic failover protection during replacement or failure. Hot-swappable design enables true zero-downtime power management for mission-critical systems.

Universal Input and Fanless Efficiency

Supporting 100-240V AC input, the power supply offers global compatibility with plug-and-play, tool-free installation. Fanless cooling uses chassis airflow for quiet, reliable operation across a wide temperature range.

TAA-Compliant and Built for Longevity

Fully TAA-compliant and engineered for durability, the power supply ensures dependable performance for high-density fiber and media-conversion systems in data centers, metro backbones, and other critical networks.

Specification

Product
Product id	1012749
Brand	StarTech.com
Partnr	MCM-CHASSIS-PSU
EAN/UPC code	065030917063
Warranty (months)	2 Years
Endurance
Mean time between failures (MTBF)	50000 uur
Power
Total power	130 W
AC input voltage	100 - 240 V
Input current	2.5 A
Performance
Purpose	Network media converter
Compatible products	MCM15-MEDIA-CHASSIS
Design
Product colour	Black
Technical details
Compliance certificates	Federal Communications Commission (FCC), RoHS, Trade Agreements Act (TAA)
Operational conditions
Operating temperature (T-T)	-40 - 80 °C
Storage temperature (T-T)	-40 - 80 °C
Operating relative humidity (H-H)	10 - 95 procent
Weight & dimensions
Width	50.8 mm
Depth	101.6 mm
Height	25.4 mm
Packaging data
Package width	215 mm
Package depth	220 mm
Package height	102 mm
Package weight	300 g
Logistics data
Master (outer) case width	330 mm
Master (outer) case length	580 mm
Master (outer) case height	510 mm
Quantity per master (outer) case	14 stuk(s)
Other features
Manual	Y
Product type	Power supply unit (PSU)
