Share a mouse, keyboard, USB hub, and dual 4K 60Hz DisplayPort monitors, between two DisplayPort-enabled computers, featuring dual-view video matrix capabilities

The Video Matrix KVM Switch allows you to view one display from each connected computer and switch the keyboard, mouse, and audio device between the selected displays using hotkeys. You can also switch all connected peripherals and both monitors like a standard KVM.

Universal Compatibility

The TAA-Compliant KVM Switch provides BIOS/UEFI control and works with any operating system, including Windows, macOS, and Linux. No software is required, and it is compatible with all hardware platforms such as Intel, AMD, and Apple Silicon.

Customizable Switching

Switching KVM ports is easy with the front-facing push button, hotkeys, or the included remote selector cable. An audible buzzer provides confirmation, and LEDs offer quick visual port selection status.

Reliable Performance

The durable design features a steel housing that helps prevent Electro-Magnetic Interference (EMI), enhancing the stability and reliability of the KVM. Its sturdy construction makes it ideal for installation in a variety of environments, and it offers 8kV Air/6kV Contact ESD protection.

USB Audio

Eliminate the need to connect 3.5mm cables from the computers to the KVM by using this KVM switch's built-in USB audio device, which provides 3.5mm audio jacks for both microphone and speakers. This setup simplifies your workspace by integrating audio management directly into the KVM switch.

Enhance Productivity and Device Management with the StarTech. com Connectivity Tools Application

Developed to improve performance and security, StarTech. com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:

• Advanced Windows Layout Utility: Setup and save custom windows layouts.
• USB Event Monitoring Utility: Track and log connected USB devices.

For more information and to download the StarTech. com Connectivity Tools application, please visit: www. startech. com/connectivity-tools

The StarTech. com Advantage

Specification

Product
Product id	987265
Brand	StarTech.com
Partnr	P2ADD121D-KVM-SWITCH
EAN/UPC code	065030904346
Warranty (months)	2 Years
Ports & interfaces
Number of computers controlled	2
Keyboard port type	USB
Mouse port type	USB
Video port type	DisplayPort
DisplayPorts quantity	4
DisplayPort version	1.2
USB 2.0 Type-B ports quantity	2
Console ports	3.5mm headphone, 3.5mm mic, DisplayPort, USB A
Console USB ports quantity	4
USB hub	Y
USB 2.0 Type-A hub ports quantity	2
Console DisplayPorts ports quantity	2
Audio connections	Y
Headphone outputs	1
Number of microphone inputs	1
DC-in jack	Y
Performance
HD type	4K Ultra HD
Maximum resolution	3840 x 2160 Pixels
Data transfer rate (max)	0.48 Gbit/s
Scan interval	10, 20, 30, 40, 50, 60 s
Daisy chain	N
Audio channels	2.0
Design
Rack mounting	N
Product colour	Black
Housing material	Aluminium, Steel
Wired remote switch	Y
LED indicators	Y
Push button	Y
Hot keys	Y
Mean time between failures (MTBF)	87298 uur
Display
Built-in display	N
On Screen Display (OSD)	N
Power
Power source	DC
Input voltage	100 - 240 V
Input current	1 A
Output voltage	12 V
Output current	3 A
Power plug type	Type M
Compatible power plug types	AU, EU, UK, US
Power consumption (typical)	36 W
Sustainability
Compliance certificates	Federal Communications Commission (FCC), RoHS, Trade Agreements Act (TAA)
Packaging data
Package width	250 mm
Package depth	292 mm
Package height	78 mm
Package weight	1500 g
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 90 procent
Weight & dimensions
Width	105 mm
Depth	221 mm
Height	26 mm
Weight	626 g
Packaging content
Quick installation guide	Y
AC adapter included	Y
Logistics data
Master (outer) case width	539 mm
Master (outer) case length	419 mm
Master (outer) case height	333 mm
Quantity per master (outer) case	10 stuk(s)
Other features
IP control	N
