Control up to eight USB and HDMI-enabled computers from a single keyboard, mouse, and 4K 60Hz HDMI monitor

The 4K 60Hz rackmount KVM switch allows switching between eight HDMI-enabled computers, sharing a keyboard, mouse, audio, 4-port USB 2.0 hub, and a 4K 60Hz HDMI 2.0 monitor. This enables effortless multi-system management, improved workspace efficiency, and enhanced productivity.

No Drivers or Software

The TAA-Compliant 8-Port KVM Switch is universally compatible, providing BIOS-level control and working with any operating system, including Windows, Windows ARM, macOS, ChromeOS, and Linux. It is also compatible with all hardware platforms such as Intel, AMD, SnapDragon/ARM, and Apple Silicon.

Multiple Switching Options

Ensures efficient and user-friendly operation for multi-server administration with switching via push-buttons or hotkeys, an audible buzzer for confirmation, and LEDs for quick visual port selection status.

Rack Mount Kit Included

The KVM switch offers a space-saving solution for managing multiple servers directly within a rack. It includes rack-mount brackets for installation in 1U of rack space on network racks and is compatible with 19-inch server racks that have a mounting depth of 6.5 inches (165mm) or more. It also complies with ANSI/EIA RS-310-D standards.

To ensure flexibility to choose the best cables for your specific installation, the KVM switch does not include cables. StarTech. com offers a wide variety of HDMI, USB, and 3.5mm audio cables in assorted lengths to suit different installation needs.

Enhance Productivity and Device Management with the StarTech. com Connectivity Tools Application

Developed to improve performance and security, StarTech. com Connectivity Tools is the only software suite on the market that works with a wide range of IT connectivity accessories. The software suite includes:

• Advanced Windows Layout Utility: Setup and save custom windows layouts.
• USB Event Monitoring Utility: Track and log connected USB devices.

For more information and to download the StarTech. com Connectivity Tools application, please visit: www. startech. com/connectivity-tools

The StarTech. com Advantage

Specification

Product
Product id	987274
Brand	StarTech.com
Partnr	R8AH202-KVM-SWITCH
EAN/UPC code	065030907231
Warranty (months)	2 Years
Ports & interfaces
Number of computers controlled	8
Keyboard port type	USB
Mouse port type	USB
Video port type	HDMI
HDMI ports quantity	8
HDMI version	2.0
USB 2.0 Type-B ports quantity	8
Console ports	3.5mm headphone, HDMI, USB A
Console USB ports quantity	4
Headphone outputs	1
Number of microphone inputs	8
DC-in jack	Y
Performance
HD type	4K Ultra HD
Maximum resolution	3840 x 2160 Pixels
Data transfer rate (max)	0.48 Gbit/s
Scan interval	10, 20, 30, 40, 50, 60, 70, 80, 90, 100 s
Daisy chain	N
Audio channels	2.0
Design
Rack capacity	1U
Rack mounting	Y
Product colour	Black
Housing material	Zinc
LED indicators	Y
Push button	Y
Hot keys	Y
Mean time between failures (MTBF)	73905 uur
Display
Built-in display	N
On Screen Display (OSD)	N
Power
Power source	DC
Input voltage	100 - 240 V
Input current	1 A
Output voltage	12 V
Output current	3 A
Power plug type	Type M
Compatible power plug types	AU, EU, UK, US
Power consumption (typical)	36 W
Sustainability
Compliance certificates	Federal Communications Commission (FCC), Trade Agreements Act (TAA)
Packaging data
Package width	435 mm
Package depth	288 mm
Package height	70 mm
Package weight	2300 g
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 90 procent
Weight & dimensions
Width	164 mm
Depth	300 mm
Height	44 mm
Weight	1500 g
Packaging content
Quick installation guide	Y
Rack mount kit	Y
Logistics data
Master (outer) case width	585 mm
Master (outer) case length	545 mm
Master (outer) case height	270 mm
Quantity per master (outer) case	5 stuk(s)
Other features
IP control	N
