Facilitate ultra high-performance connectivity between Thunderbolt 5-enabled devices

Experience reliable, ultra-high performance between Thunderbolt 5-enabled devices, supporting up to twice the bandwidth of Thunderbolt 4, 8K 60Hz video, and 240W charging over a single connection. This Thunderbolt 5 cable is ideal for high-performance laptops such as 16in MacBook Pro with M4 Pro/Max.

Enhanced Bandwidth with Boost Mode

Transfer high-speed data and drive dual UHD displays with 80 Gbps bidirectional bandwidth. When higher bandwidth is required, Thunderbolt 5 Boost Mode reallocates the data lanes, enabling 120 Gbps (transmit) and 40 Gbps (receive). This asymmetric configuration is ideal for display-intensive tasks, such as driving multiple 8K monitors or handling high-resolution video workflows while still supporting robust data transfer capabilities.

Seamless Compatibility

Connect this Intel Thunderbolt-certified cable for guaranteed Thunderbolt 5 performance and backward compatibility. Certified cables ensure seamless operation across multiple resolutions, refresh rates, and resource-intensive applications.

Durable Design

The Thunderbolt 5 cable features a flexible TPE outer jacket that is tested to withstand 2, 000 bending cycles and routes easily around corners and desk edges. Robust strain reliefs enable convenient positioning of the cable. The durable Nickel-plated connectors are rated to operate beyond 10, 000 insertions.

Supported Thunderbolt 5 Features

This Certified Thunderbolt 5 Cable supports full Thunderbolt 5 performance:

• 80 Gbps bidirectional bandwidth, doubling the capacity of Thunderbolt 4
• 120 Gbps boost mode for display-intensive applications
• DisplayPort 2.1 Alt Mode: Up to 8K 60Hz/4K 240Hz video with DSC, HDR, and 10-bit color
• PCI Express 4.0 (64 Gbps) support for GPUs, NICs, and storage in PCIe chassis
• 240W Power Delivery EPR for charging for high-performance laptops
• Backward Compatibility with Thunderbolt 4/3, USB4 (40 Gbps), and USB 3.2 (10 Gbps)

This versatile Thunderbolt 5 cord is constructed with braided alloy shielding to minimize EMI for seamless and consistent data/video output and long-term reliable performance.

Specification

Product
Product id	1008771
Brand	StarTech.com
Partnr	TBLT5MM1M240WWH
EAN/UPC code	065030917483
Warranty (months)	Lifetime
Features
Connector 1	Male
Connector 2	Male
Cable length	1 m
Data transfer rate (max)	120 Gbit/s
Product colour	White
Connector contacts plating	Nickel
Cable shape	Round
Quantity per pack	1 stuk(s)
USB Power Delivery	Y
USB Power Delivery up to	240 W
Maximum resolution	7680 x 4320 Pixels
USB Type-C DisplayPort Alternate Mode	Y
AWG wire size	30/34
Jacket material	Thermoplastic Elastomer (TPE)
High Dynamic Range (HDR) supported	Y
Thunderbolt version	5
Weight	43 g
Weight & dimensions
Cable diameter	4.6 mm
Operational conditions
Operating temperature (T-T)	10 - 40 °C
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 85 procent
Certificates
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Logistics data
Quantity per master (outer) case	60 stuk(s)
Master (outer) case length	292 mm
Master (outer) case width	435 mm
Master (outer) case height	205 mm
Packaging data
Package width	128 mm
Package depth	220 mm
Package height	20 mm
Package weight	40 g
