High-Speed Dual Band WiFi for Better Connections
The Archer A5 lets your PC or laptop enjoy connections 3x faster than Wireless N with Wireless AC technology. With 300Mbps over the 2.4GHz band and 867Mbps over the the crystal clear 5GHz band, the Archer A5 is the superior choice for seamless HD streaming, online gaming and other bandwidth-intensive tasks.

Easily Manage Your Network
Extensive device management capabilities allow you to freely adjust settings for every device connected to your router.

Bandwidth Control
Enables bandwidth management allowing you to allocate more data for gaming or streaming or limit connection speeds to keep people on task.

Guest Network
Provides secure access for guests to connect to your WiFi network. Easily share your network without compromising security.

Parental Controls
Allows the network administrator to restrict for children, limit access levels and connection time.

Access Control
Select what devices are allowed to connect to your network to keep it secure.

Easy Setup and Use
Set up the Archer A5 in minutes thanks to its intuitive web interface and the powerful Tether app. Tether also lets you manage your network settings from any Android or iOS device, including parental controls and access control.

WPS
Make secure wireless connections quick and easy with the push of a button.

IPv6
Supports IPv6 which helps you future-proof your network.

Security
Protects your home network with firewalls and wireless encryption.

Specification

Product
Product id	606403
Brand	TP-Link
Partnr	ARCHER A5
EAN/UPC code	6935364084134
WAN connection
Ethernet WAN	Y
DSL WAN	N
SIM card slot	N
WAN connection type	RJ-45
Wireless LAN features
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Network
Ethernet LAN	Y
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10, 100 Mbit/s
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Port forwarding	Y
Dynamic DNS (DDNS)	Y
Static route	Y
VPN Passthrough	Y
Receiver sensitivity	5GHz: 11a 54M: -73dBm 11ac VHT20 MCS8: -68dBm 11ac VHT40 MCS9: -64dBm 11ac VHT80 MCS9: -60dBm 2.4GHz: 11g 54M: -76dBm 11n HT20 MCS7: -74dBm 11n HT40 MCS7: -71dBm
Mobile network
3G	N
4G	N
Ports & interfaces
Ethernet LAN (RJ-45) ports	4
USB port	N
Memory card slot(s)	N
Management features
Reset button	Y
WPS push button	Y
Security
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall	Y
Access Control List (ACL)	Y
DoS attack prevention	Y
Filtering	Y
MAC address filtering	Y
IP address filtering	Y
DMZ support	Y
Protocols
DHCP client	Y
DHCP server	Y
Universal Plug and Play (UPnP)	Y
Supported network protocols	IPv4, IPv6
Design
Product type	Tabletop router
Product colour	Black
Antenna
Antenna type	External
Antennas quantity	4
Features
Certification	CE, FCC, RoHS
Power
Power source type	DC
Output voltage	9 V
Output current	0.85 A
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 procent
Storage relative humidity (H-H)	5 - 90 procent
System requirements
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows Vista, Windows XP
Linux operating systems supported	Y
Mac operating systems supported	macOS
Mac compatibility	Y
Weight & dimensions
Width	229.87 mm
Depth	144.19 mm
Height	36.85 mm
Packaging data
Cables included	LAN (RJ-45)
AC adapter included	Y
Quick installation guide	Y
