TP-Link Omada EAP603-Outdoor. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1800 Mbit/s. Security algorithms: EAP, EAP-FAST, EAP-GTC, EAP-MD5, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, PEAP, PPSK, SNMP, SSH,. . . . Ethernet LAN data rates: 10, 100, 1000 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 4.8 W

Specification

Product
Product id	996986
Brand	TP-Link
Partnr	EAP603-OUTDOOR
EAN/UPC code	1210002605731
Management features
Web-based management	Y
Cloud-managed	Y
Backup function	Y
Packaging data
PoE adapter included	Y
Mounting kit	Y
Quick start guide	Y
Features
2.4 GHz	Y
5 GHz	Y
Maximum data transfer rate	1800 Mbit/s
6 GHz	N
Maximum data transfer rate (2.4 GHz)	573 Mbit/s
Maximum data transfer rate (5 GHz)	1201 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Bluetooth	Y
Maximum outdoor range	300 m
Security
Security algorithms	EAP, EAP-FAST, EAP-GTC, EAP-MD5, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, PEAP, PPSK, SNMP, SSH, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
MAC address filtering	Y
IP address filtering	Y
Service Set Identifier (SSID) features	Multiple SSIDs
Number of SSID supported	16
Guest access	Y
Remote Authentication Dial-In User Service (RADIUS)	Y
Access Control List (ACL)	Y
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Power
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) type supported	Passive PoE
DC voltage range	42.5 - 57 V
Input current	0.36 A
Power consumption (max)	4.8 W
Design
Placement	Pole, Wall
Product colour	White
International Protection (IP) code	IP65, IP66
Antenna
Antenna type	Internal & External
Antenna direction type	Omni-directional
Antennas quantity	4
Antenna gain level (max)	5 dBi
Operational conditions
Operating relative humidity (H-H)	10 - 90 procent
Operating temperature (T-T)	-30 - 70 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 procent
Technical details
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Weight & dimensions
Width	230 mm
Depth	207.5 mm
Height	69.7 mm
