Seamless Coverage to Remove Dead Zones
EAP673-Extender, featuring four high-gain antennas and mesh technology, eliminates dead zones, extending coverage by 1500 ft² (140 m²) . Enjoy seamless roaming for uninterrupted connectivity.

Effortless Installation with AC Power
Overcome cabling challenges with EAP673-Extender, delivering seamless Wi-Fi via AC power. Enjoy stable, high-performance coverage—no extra wires needed.

AP Mode for Flexible Deployment
EAP673-Extender's built-in AP mode delivers a robust, stable Wi-Fi signal without a PoE switch or infrastructure renovations, enhancing flexibility and reducing costs.

Specification

Product
Product id	975035
Brand	TP-Link
Partnr	EAP673-EXTENDER
EAN/UPC code	8885020622874
Performance
Type	Network repeater
Ethernet LAN data rates	10, 100, 1000 Mbit/s
BeamForming	Y
Antenna
Antennas quantity	4
Antenna type	External
Transmitting power (CE)	<20 dBm (2.4 GHz, EIRP) <23 dBm (5 GHz, band1 & band2, EIRP) <30 dBm (5 GHz, band3, EIRP) dBm
Transmitting power (FCC)	<25 dBm (2.4 GHz) <28 dBm (5 GHz) dBm
Network
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wi-Fi	Y
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Wi-Fi data rate (max)	4800 Mbit/s
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Design
Product colour	White
Housing material	Polycarbonate (PC)
Quantity per pack	1 stuk(s)
Reset button	Y
Power
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	18 W
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 procent
Storage relative humidity (H-H)	5 - 90 procent
Weight & dimensions
Width	80 mm
Depth	37.8 mm
Height	160 mm
Weight	436.6 g
Certificates
Compliance certificates	CE, Federal Communications Commission (FCC), JRF, RCM, RoHS, UL, VCCI
Management features
Airtime scheduling	Y
Packaging content
Quick start guide	Y
