Product |
Product id
| 949941
|
Brand
| TP-Link
|
Partnr
| EAP683 UR
|
EAN/UPC code
| 8885020621938
|
Management features |
Syslog
| Y
|
Firmware upgradeable
| Y
|
Packaging data |
Number of products included
| 1 stuk(s)
|
Mounting kit
| Y
|
Quick start guide
| Y
|
Package type
| Box
|
Features |
2.4 GHz
| Y
|
5 GHz
| Y
|
Maximum data transfer rate
| 6000 Mbit/s
|
6 GHz
| N
|
Maximum data transfer rate (2.4 GHz)
| 1148 Mbit/s
|
Maximum data transfer rate (5 GHz)
| 4804 Mbit/s
|
Ethernet LAN data rates
| 10, 100, 1000, 2500 Mbit/s
|
Frequency band
| 2.4 - 6 GHz
|
Networking standards
| IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
|
Number of users
| 510 gebruiker(s)
|
Automatic channel selection
| Y
|
Automatic channel scanning
| Y
|
MIMO
| Y
|
MIMO type
| Multi User MIMO
|
Fast roaming
| Y
|
VLAN support
| Y
|
Rate limiting
| Y
|
Band steering
| Y
|
Airtime Fairness (ATF)
| Y
|
Quality of Service (QoS) support
| Y
|
BeamForming
| Y
|
Security |
Security algorithms
| HTTPS, SNMP, SNMPv2, SNMPv3, SSH
|
MAC address filtering
| Y
|
Service Set Identifier (SSID) features
| Multiple SSIDs
|
Access Control List (ACL)
| Y
|
Ports & interfaces |
Ethernet LAN (RJ-45) ports
| 1
|
DC-in jack
| Y
|
Power |
Power over Ethernet (PoE)
| Y
|
DC voltage range
| 12 V
|
Design |
Placement
| Ceiling, Wall
|
Product colour
| White
|
Reset button
| Y
|
LED indicators
| Y
|
Antenna |
Antenna type
| Internal
|
Antenna direction type
| Omni-directional
|
Antenna gain level (max)
| 5 dBi
|
Operational conditions |
Operating relative humidity (H-H)
| 10 - 90 procent
|
Operating temperature (T-T)
| 0 - 40 °C
|
Storage temperature (T-T)
| -40 - 70 °C
|
Storage relative humidity (H-H)
| 5 - 90 procent
|
Weight & dimensions |
Width
| 220 mm
|
Depth
| 220 mm
|
Height
| 32.5 mm
|
