Optimized Wired Performance with 2.5G PoE+ Port
With a 2.5 Gigabit Ethernet Port, EAP720 delivers remarkable multi-gigabit performance for higher bandwidth and faster WiFi. Compatibility with 802.3at PoE is ideal for flexible deployment.

Specification

Product
Product id	994912
Brand	TP-Link
Partnr	EAP720
EAN/UPC code	1210002608732
Warranty (months)	3 year limited warranty
Management features
Web-based management	Y
Syslog	Y
Cloud-managed	Y
Access point management	Wi-Fi schedule
Firmware upgradeable	Y
Packaging data
AC adapter included	Y
Mounting kit	Y
Quick start guide	Y
Package width	245 mm
Package depth	228 mm
Package height	65 mm
Package weight	792 g
Features
2.4 GHz	Y
5 GHz	Y
Maximum data transfer rate	4324 Mbit/s
6 GHz	N
Maximum data transfer rate (2.4 GHz)	688 Mbit/s
Maximum data transfer rate (5 GHz)	4324 Mbit/s
Ethernet LAN data rates	2500 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.1Q, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3x
Channel bandwidth	240 MHz
Coverage area	140 m²
Spread spectrum method	OFDMA
Wi-Fi Multimedia (WMM)/(WME)	Y
VLAN support	Y
Rate limiting	Y
Airtime Fairness (ATF)	Y
Quality of Service (QoS) support	Y
BeamForming	Y
Maximum Tx power (2.4 GHz)	25 dBmW
Maximum Tx power (5 GHz)	25 dBmW
Security
Security algorithms	EAP-AKA, EAP-FAST, EAP-GTC, EAP-MD5, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, PEAP, PPSK, SNMP, SNMPv2, SNMPv3, SSH, SSID, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
MAC address filtering	Y
Schedule access	Y
Guest access	Y
Remote Authentication Dial-In User Service (RADIUS)	Y
Access Control List (ACL)	Y
Protocols
DHCP client	Y
Supported network protocols	IPv4/IPv6
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
DC-in jack	Y
Power
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) type supported	PoE+
DC voltage range	12 V
Input current	1.5 A
Power consumption (max)	17.83 W
Design
Placement	Ceiling, Wall
Product colour	White
Reset button	Y
LED indicators	Y
Antenna
Antenna type	Internal
Performance
Internal memory	4096 MB
Flash memory	128 MB
Operational conditions
Operating relative humidity (H-H)	10 - 90 procent
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 procent
Technical details
Compliance certificates	CE, Federal Communications Commission (FCC), Industry Canada (IC), RoHS
Weight & dimensions
Width	160 mm
Depth	160 mm
Height	36.7 mm
Weight	410 g
