Ultra-Thin Enterprise WiFi 7 Access Point

- Next-Gen WiFi 7
- Wi-Fi Speeds up to 9214 Mbps
- Multi-Link Operation (MLO)
- 1× 2.5G RJ45 Port
- PoE Power
- Ultra-Thin Design
- Centralized Cloud Management
- Omada Mesh Technology

Ultra-Thin Design for Flexible Deployment
The overall design of EAP772 utilizes a thinner circular arc with a groove around the top cover, fitting closer to various installation surfaces such as ceilings. The compact internal hardware layout and heat-dissipating design ensure high performance with a sharp aesthetic.

Boosted Network Security

- Secure Guest Network with up to 24 SSIDs
- Boost Your Business with SMS Login
- WPA3 for Worry-Free Open Public Networks
- Rogue AP Detection

Specification

Product
Product id	978684
Brand	TP-Link
Partnr	EAP772-OUTDOOR
EAN/UPC code	1210002602280
Warranty (months)	3 Years
Management features
Web-based management	Y
Packaging data
AC adapter included	N
Mounting kit	Y
Features
2.4 GHz	Y
5 GHz	Y
Maximum data transfer rate	9300 Mbit/s
6 GHz	Y
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Maximum data transfer rate (5 GHz)	2880 Mbit/s
Maximum data transfer rate (6 GHz)	5760 Mbit/s
Ethernet LAN data rates	2500 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n
Number of users	380 gebruiker(s)
Bluetooth	Y
Bluetooth version	5.2
MIMO	Y
MIMO type	Multi User MIMO
VLAN support	Y
Airtime Fairness (ATF)	Y
Quality of Service (QoS) support	Y
BeamForming	Y
Security
Security algorithms	SNMP, SNMPv2, SNMPv3, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
MAC address filtering	Y
Service Set Identifier (SSID) features	Multiple SSIDs
Number of SSID supported	24
Remote Authentication Dial-In User Service (RADIUS)	Y
Access Control List (ACL)	Y
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Design
Placement	Ceiling, Wall
Product colour	White
LED indicators	Y
Certification	CE, FCC, RoHS, IC
Antenna
Antenna type	Internal
Operational conditions
Operating relative humidity (H-H)	10 - 90 procent
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 procent
Packaging content
Quantity per pack	1 stuk(s)
Weight & dimensions
Width	220 mm
Depth	220 mm
Height	32.5 mm
