Omada Central Essentials — A Free and Easy Cloud-Based Network Management

Omada Central Essentials is a free, easy-to-use version of the Omada Central.
It provides cloud-based centralized management and monitoring for the Omada networking system, covering access points, switches, and gateways, ideal for surveillance networks and small businesses.

Multiple Application Scenarios

Surveillance

Works with IP Cameras

Wi-Fi Coverage

Works with Access Points

Wired Connections

Works with Non-PoE Devices such as PCs and Printers

Specification

Product
Product id	1009185
Brand	TP-Link
Partnr	ES228GP
EAN/UPC code	1210002609760
Warranty (months)	3 year limited warranty for normal product and 5 year warranty for managed switch
Data transmission
MAC address table	8000 entries
Switching capacity	56 Gbit/s
Forwarding rate	41.67 Mpps
Store-and-forward	Y
Number of queues	8
Jumbo frames support	Y
Jumbo frames	15000
Packet buffer memory	4 MB
Network
Networking standards	IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Port mirroring	Y
Flow control support	Y
Broadcast storm control	Y
Link aggregation	Y
VLAN support	Y
Virtual LAN features	MTU VLAN, Port-based VLAN, Tagged VLAN
Management features
Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Y
Web-based management	Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	26
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP module slots quantity	2
Security
DHCP features	DHCP client
IGMP snooping	Y
Queue scheduling algorithms	Weighted Round Robin (WRR)
Loop protection	Y
Weight & dimensions
Width	440 mm
Depth	180 mm
Height	44 mm
Packaging data
Cables included	AC
Manual	Y
Power
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input current	4 A
Power protection features	Surge protection
Design
Rack mounting	Y
Product colour	Black
Number of fans	2 ventilator(en)
Operational conditions
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90 procent
Operating temperature (T-T)	-5 - 45 °C
Operating relative humidity (H-H)	10 - 90 procent
Technical details
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Y
Power over Ethernet (PoE) type supported	PoE+
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	250 W
