TP-Link INSIGHT S345ZI. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: White, Form factor: Bullet. Lens viewing angle, horizontal: 29.6–102.0, Lens viewing angle, vertical: 16.8–53.8, Lens viewing angle, diagonal: 34.1–122.8. Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9"). Optical zoom: 5x, Detect distance: 207 m, Observe distance: 86 m

Specification

Product
Product id	985486
Brand	TP-Link
Partnr	INSIGHT S345ZI
EAN/UPC code	8885020623574
Performance
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Maximum operating distance	60 m
Wide Dynamic Range (WDR)	Y
Day/night mode	Y
Remote viewing	Y
Infrared (IR) cut-off filter	Y
Dynamic range	120 dB
Design
Form factor	Bullet (shape)
Mounting type	Wall
Product colour	White
Housing material	Metal
Protection features	Waterproof
International Protection (IP) code	IP67
Weatherproof	Y
Camera
Lens viewing angle, horizontal	29.6–102.0 °
Lens viewing angle, vertical	16.8–53.8 °
Tilt angle range	0 - 90 °
Lens viewing angle, diagonal	34.1–122.8 °
Camera shutter speed	1/3 to 1/10000 s
Image sensor
Sensor type	CMOS
Optical sensor size	1/2.9 "
Progressive scan	Y
Lens system
Optical zoom	5 x
Detect distance	207 m
Observe distance	86 m
Recognize distance	41 m
Focus	Motorized
Maximum aperture number	1.6
Identify distance	21 m
Focal length range	2.7 - 13.5 mm
Night vision
Night vision	Y
LED type	IR
Video
Maximum resolution	2688 x 1520 Pixels
Total megapixels	4 MP
Video compression formats	H.264, H.264+, H.265, H.265+
Supported graphics resolutions	1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520
Video recording	Y
Noise reduction	Y
Digital Wide Dynamic Range (DWDR)	Y
Highlight Compensation (HLC)	Y
Back Light Compensation (BLC)	Y
Bit rate	Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 512 Kbps to 1024 Kbps
Image quality adjustment	Brightness, Contrast, Mirror, Saturation, Sharpness
Bit rate control	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Audio
Built-in speaker(s)	Y
Audio system	1-way
Audio input channels	1
Audio output channels	1 kanalen
Audio formats supported	G.711 A-law
Built-in microphone	Y
Sample rate	8 kHz
Number of microphones	1
Audio detection	Y
Bit rate range	0 - 64 Kbit/s
Network
Ethernet LAN	Y
Wi-Fi	N
Bluetooth	N
Networking standards	IEEE 802.3af, IEEE 802.3at
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Live view	Y
Storage
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
DC-in jack	Y
Security
Built-in siren	Y
Password protection	Y
Video motion detection	Y
Motion sensor	Y
Mirror	Y
Human and vehicle targets classification	Y
Alert notification type	Push notification
Digest authentication	Y
IP address filtering	Y
HTTPS encryption	Y
Management features
Web-based management	Y
Web browser	Y
Cloud-managed	Y
Reset button	Y
Power
Power source type	DC, PoE
Power consumption (max)	10.8 W
Power consumption (Power over Ethernet (PoE))	12 W
DC output voltage	12
Operational conditions
Operating temperature (T-T)	-30 - 60 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	0 - 95 procent
Storage relative humidity (H-H)	0 - 95 procent
Weight & dimensions
Width	100 mm
Height	101 mm
Length	256 mm
Package type	Box
Packaging content
Number of cameras	1
