360° Coverage with 4-in-1 Cameras
A single fisheye camera can play the role of many, providing a simpler and more competitive security solution. For example, in 4PTZ display mode, it functions as four cameras at once, delivering complete coverage and flexible perspectives.

Multiple Display Modes
Along with the fisheye view, VIGI provides multiple display modes, enabling you to focus on every detail exactly as you prefer.

Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.

Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.

3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.

White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.

Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.

Specification

Product
Product id	985488
Brand	TP-Link
Partnr	INSIGHT S655I
EAN/UPC code	8885020627848
Warranty (months)	3 year limited warranty
Performance
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Y
Certification	CE; NTRA; KC; FCC; VCCI; BSMI; ONVIF
Dynamic range	120 dB
Design
Mounting type	Ceiling/Wall
Product colour	White
Housing material	Metal
International Protection (IP) code	IP67
IK code	IK10
Weatherproof	Y
Camera
Number of Privacy masking areas	4
Image sensor
Sensor type	CMOS
Optical sensor size	1/2.7 "
Panoramic camera
Signal-to-Noise Ratio (SNR) (panoramic camera)	52 dB
Sensor type (panoramic camera)	CMOS
Digital Wide Dynamic Range (DWDR) (panoramic camera)	Y
Lens system
Detect distance	28.8 m
Observe distance	12 m
Recognize distance	5.7 m
Identify distance	2.8 m
Fixed focal length	1.44 mm
Night vision
Night vision	Y
Night vision distance	30 m
LED type	IR
Number of illumination LEDs	4
Infra-red wavelength	850 nm
Video
Maximum resolution	2560 x 1920 Pixels
Total megapixels	5 MP
Video compression formats	H.264, H.264+, H.265, H.265+
Supported graphics resolutions	320 x 240, 640 x 480 (VGA), 1280 x 960, 2048 x 1536 (QXGA), 2560 x 1920
Digital Wide Dynamic Range (DWDR)	Y
Highlight Compensation (HLC)	Y
Region of Interest (ROI) encoding	Y
Back Light Compensation (BLC)	Y
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Audio
Built-in speaker(s)	Y
Audio system	2-way
Built-in microphone	Y
Sample rate	8 kHz
Number of microphones	1
Bit rate range	0 - 64 Kbit/s
Network
Ethernet LAN	Y
Wi-Fi	N
Bluetooth	N
Ethernet interface type	Fast Ethernet
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Supported network protocols	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Storage
Built-in HDD	N
Card reader integrated	Y
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	512 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports	1
Security
Password protection	Y
Motion sensor	Y
Alert notification type	E-mail, Push notification
Digest authentication	Y
IP address filtering	Y
HTTPS encryption	Y
Management features
Web browser	Y
Cloud-managed	Y
Reset button	Y
Power
Power source type	DC, PoE
Operational conditions
Operating temperature (T-T)	-30 - 60 °C
Storage temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	0 - 95 procent
Storage relative humidity (H-H)	0 - 95 procent
Weight & dimensions
Height	56 mm
Diameter	132 mm
Weight	440 g
